MOUNTING
Mount gun ush boxes to a sturdy metal stand,
wall, or support that is connected to an earth
ground. Conductive metal ushing / solvent waste
container should be positioned directly below the
ush box.
Mount box with 4 ea. 1/4” or 6mm diameter screws
using dimensions shown at right. Remove the gun
saddle from the box to make mounting easier.
GUN FLUSH BOX KIT
Gun ush boxes are used to improve safety and minimize solvent usage and time when compared to manual
ushing of spray guns. Higher solvent and air pressures may be used, improving ushing efciency.
Flush boxes may be installed on the GEMS system for one or two guns. In a two-gun installation the system
controller allows either gun 1 or both guns 1 and 2 to ush and load paint. The second gun may be disabled
by the administrator if necessary.
All pneumatic connections to the gun ush box are for 5/32” (4mm) OD tubing.
The gun flush box(es) must be enabled in the system software configuration, accessible only
by distributor. Contact distributor for installation and proper kit functionality.
!
CAUTION
Gun flush box(es) will generate vapors and
mists of paint and solvent and therefore
must be mounted in a spray booth or other
Class 1 Division 1 [Zone 1] Hazardous Area.
The gun flush box and conductive metal
waste container used for flushing must be
bonded to earth ground and continuity
checked with an ohmmeter .
Do NOT operate the gun flush box until
properly grounded.
!
WARNING
GUN BOX MOUNTING HOLE PATTERN
