Service/Repair Instructions
Ensure mains water is
turned off & disconnect from stop cock.
Flush water supply line before
connecting to stop cock & turn mains
water back on.
Using pliers carefully remove tail strainer from the base of the
valve.
Wash tail strainer to
remove any dirt.
Carefully replace
strainer back into
valve tail.
Push & rotate
anti-clockwise to
re-attach cap
assembly.
Replace seal onto
cap assembly.
Wash seal to
remove any dirt and
inspect for damage.
Remove seal from
cap assembly.
Rotate clockwise &
pull to remove cap
assembly.
Cap Assembly
Seal
Helplines
Australia 1300 CAROMA (1300 227 662)
New Zealand +64 9 9279 2700
Caroma International +61 3 9926 5477
Caroma Industries Limited
ABN 35 000 189 499
Locked bag 20, Epping, NSW 2121, Australia
Made in China.
www.caroma.com.au
www.smartush.com.au
www.caroma.co.nz
Leaet No. 687 540~D
● C o m p a t i b l e w i t h a l l B o t t o m I n l e t C i s t e r n s
whe r e r eq u i r e d a i r - s ep a r a t i on i s ach i e v a bl e .
Service Requirements
Troubleshooting Guide
Spare Parts Information
● Quietow Inlet Valve compatible Spare Part Kit is 687 040
Containing - 1 x Cap Assembly
- 1 x Seal
Refer to - Steps 1, 2, 5 & 6 above.
● Valve slow to ll OR fails to open ► Ensure tap is open and/or clean Tail Strainer.
● Valve fails to close ► Clean & inspect seal as described above, replace Cap Assembly & Seal if damaged.
● If any other issues arise ► Consult a plumber or Caroma After Sales Service.
● Valve Seal and Inlet Strainer may require periodic cleaning (dependant on water quality).
- procedure as described above.
