NEW HOLE
STEP 7
If the locking pin does line up
please ignore step 7 & 8. If
you find that the locking pin
on the rear legs doesn’t line
up with the hole on the MK2
Carp-Porter frame, it may
be nesessary to modify the
frame and create a new hole.
STEP 8
Using the diagram above extend the existing hole so its oval, the
centre will need to be 55mm from the centre of the hole that holds
the nuts and bolts on the frame. The best way to do this is with a file.
You will now be able to locate the locking pin.
