CARPENTER CCN65Z - TYPES OF NAILS; ACCEPTABLE NAILS; STANDARD ACCESSORIES

1110
ACCEPTABLE NAILS
TESTING THE NAILER
DANGER
WARNING
Only nails shown in the Table below can be driven with this Nailer.
NOTE:
Before actually beginning the nailing work, test the Nailer by using the check list below. Conduct the
tests in the following order.
If abnormal operation occurs, stop using the Nailer and contact a Carpenter power tools immediately.
⑴ DISCONNECT AIR HOSE FROM NAILER.
REMOVE ALL NAILS FROM NAILER.
ALL SCREWS MUST BE TIGHTENED. If any screws are loose, tighten them.
Operators and others in work area MUST wear
safety glasses with side shields which conforms to ANSI Z87.1
specications.
Never use Nailer unless push lever is operating properly.
Model No. CCN65Z contact us 1-888-666-1887
TYPES OF NAILS
OPERATING INSTRUCTIONS
1-3/4"
2-1/2"
45
65
Shank dia:0.092"-0.099"
Ø2.3mm-Ø2.5mm
Head dia:0.212"-0.232"
Ø5.4mm-Ø5.9mm
STANDARD ACCESSORIES
Safety glasses
Allen wrench for M6 screw
Allen wrench for M5 screw
Allen wrench for M4 screw
Nose cap "No-mar push lever
attachment" (It is attached in the
magazine assembly)
1
2
3
4
5
1
1
1
1
1
1 2 3
4 5
