Carrier 24ACB4 Series User Manual

2
MODEL NUMBER NOMENCLATURE
123 4 567
8
N
91011 12 13
N N A A A/N N N A/N A/N A/N N N
24A C B43
6
A00 3 0
Product
Series
Product
Family
Tier
Major
Series
SEER
Cooling
Capacity
Variations Open Open Voltage
Minor
Series
0, 1, 2...
24=AC
A=RES
AC
C=
Comfort B=Puron
4=14
SEER
A=Standard
0=Not
Defined
0=Not
Defined
3=208/230--- 1
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and manufactured to
meet Energy Star® criteria for energy efficiency when
matched with ap p rop riate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
STANDARD FEATURES
FEATURES
Unit Size --- Series
18---30 24---30 30---30 36---30 42---30 48---30 60---30
Puron Refrigerant X X X X X X X
Maximum SEER Rating 15.5 16.0 16.0 16.0 16.0 15.0 14.5
Scroll Compressor X X X X X X X
Louvered Coil Guard X X X X X X X
FieldInstalledFilterDrier X X X X X X X
Front Seating Service Valves X X X X X X X
Internal Pressure Relief V alve X X X X X X X
Internal Thermal Overload X X X X X X X
Long Line capability X X X X X X X
Low A mbient capability with Kit X X X X X X X
Low Pressure (loss of charge) Switch X X X X X X X
High Pressure Switch X X X X X X X
Compressor Sound Blanket X X X X X X X
X=Standard
24ACB4

Carrier 24ACB4 Series Specifications
