Carrier 24ACB4 Series User Manual

20
DETAI LED COOLING CAPACITIES#
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l S y s.
KW**
Tot a l Sens‡ To ta l Sens‡ To tal Sens‡ Tot al Sens‡ Tot al Sens‡ Tot a l Sens‡
24ACB418A30 Outdoor Section With CAP**2414A** Indoor Section
525
72 (22.2) 21.57 11.21 1.17 20.52 10.80 1.32 19.45 10.39 1.49 18.33 9.97 1.67 17.18 9.55 1.88 15.93 9.09 2.11 67 (19.4) 19.60 13.63 1.18 18.65 13.23 1.33 17.67 12.81 1.50 16.65 12.40 1.69 15.60 11.96 1.90 14.46 11.51 2.13 62 (16.7) 17.82 16.04 1.19 16.96 15.63 1.34 16.08 15.22 1.51 15.18 14.79 1.70 14.29 14.29 1.91 13.44 13.44 2.13 57 (13.9) 17.16 17.16 1.20 16.49 16.49 1.35 15.79 15.79 1.51 15.06 15.06 1.70 14.29 14.29 1.91 13.44 13.44 2.13
600
72 (22.2) 22.01 11.78 1.19 20.92 11.37 1.34 19.79 10.95 1.51 18.62 10.52 1.70 17.42 10.09 1.91 16.12 9.62 2.14 67 (19.4) 20.03 14.54 1.21 19.03 14.13 1.36 18.00 13.71 1.53 16.94 13.28 1.71 15.84 12.84 1.92 14.66 12.37 2.15 62 (16.7) 18.27 17.29 1.22 17.38 16.86 1.37 16.50 16.41 1.54 15.70 15.70 1.72 14.86 14.86 1.93 13.95 13.95 2.16 57 (13.9) 17.96 17.96 1.22 17.23 17.23 1.37 16.48 16.48 1.54 15.70 15.70 1.72 14.87 14.87 1.93 13.95 13.95 2.16
675
72 (22.2) 22.34 12.32 1.22 21.20 11.90 1.37 20.03 11.47 1.54 18.83 11.04 1.72 17.58 10.60 1.93 16.24 10.13 2.16 67 (19.4) 20.35 15.42 1.23 19.31 15.00 1.38 18.25 14.57 1.55 17.15 14.13 1.74 16.02 13.68 1.95 14.80 13.21 2.18 62 (16.7) 18.68 18.46 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18 57 (13.9) 18.63 18.63 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CAP**2414A** 1.00 1.00
CAP**1814A** 0.99 1.02 CAP**2417A** 1.00 1.00
CNPF*2418A** 1.00 1.00
CNPH*2417A** 1.00 1.00
CNPV*1814A** 0.99 1.02 CNPV*2414A** 1.00 1.00 CNPV*2417A** 1.00 1.00
CSPH*2412A** 1.00 0.96
FE4ANF002 1.01 0.88 FF1ENP018 0.99 1.02 FF1ENP024 1.00 1.03 FV4BNF002 1.01 0.88
FX4CNF018 1.00 0.88 FX4CNF024 1.02 0.90
FY4ANF018 0.99 1.02 FY4ANF024 0.99 1.02
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CAP**1814A** 0.98 0.90 58CV(A,X)070--- 12 CAP**2414A** 0.99 0.88 58CV(A,X)070--- 12
CNPH*2417A** 0.99 0.88 58CV(A,X)070--- 12
CNPV*1814A** 0.98 0.90 58CV(A,X)070--- 12 CNPV*2414A** 0.99 0.88 58CV(A,X)070--- 12
CSPH*2412A** 0.99 0.88 58CV(A,X)070 --- 12
CAP**2417A** 0.99 0.88 58CV(A,X)090--- 16
CNPH*2417A** 0.99 0.88 58CV(A,X)090--- 16
CNPV*2417A** 0.99 0.88 58CV(A,X)090--- 16
CSPH*2412A** 0.99 0.88 58CV(A,X)090 --- 16
CAP**2417A** 1.00 0.87 58MEB040 --- 12
CNPH*2417A** 1.00 0.88 58MEB040--- 12
CNPV*2417A** 1.00 0.88 58MEB040--- 12
CSPH*2412A** 1.00 0.88 58MEB040--- 12
CAP**2417A** 1.00 0.87 58MEB060--- 12
CNPH*2417A** 1.00 0.88 58MEB060--- 12
CNPV*2417A** 1.00 0.88 58MEB060--- 12
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CSPH*2412A** 1.00 0.88 58MEB060--- 12
CNPH*2417A** 0.99 0.88 58MV(B,C)040--- 14
CSPH*2412A** 0.99 0.88 58MV(B,C)040--- 14
CAP**2417A** 0.99 0.88 58MV(B,C)060--- 14
CNPH*2417A** 0.99 0.88 58MV(B,C)060 --- 14
CNPV*2417A** 0.99 0.88 58MV(B,C)060--- 14
CSPH*2412A** 0.99 0.88 58MV(B,C)060--- 14
CNPH*2417A** 0.99 0.88 58MV(B,C)080 --- 14
CSPH*2412A** 0.99 0.88 58MV(B,C)080--- 14
CAP**1814A** 1.00 0.90 58PH*045--- 08 CAP**2414A** 1.01 0.89 58PH*045--- 08
CNPH*2417A** 1.01 0.89 58PH*045--- 08
CNPV*1814A** 1.00 0.90 58PH*045--- 08 CNPV*2414A** 1.01 0.89 58PH*045--- 08
CSPH*2412A** 1.01 0.89 58PH*045--- 08
See notes on page 29
24ACB4
