22
DETAI LED COOLING CAPACITI ES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Tot a l Sens‡ Tot al Sens‡ To t al Sens‡ Tota l Sens‡ To tal Sens‡ To t al Sens‡
24ACB430A30 Outdoor Section With CAP**3014A* Indoor Section
875
72 (22.2) 34.32 17.27 1.96 32.83 16.71 2.19 31.24 16.13 2.44 29.59 15.54 2.71 27.80 14.90 3.01 25.81 14.20 3.34 67 (19.4) 31.45 21.21 1.96 30.06 20.64 2.18 28.59 20.05 2.43 27.04 19.44 2.71 25.38 18.78 3.01 23.54 18.08 3.33 62 (16.7) 28.82 25.13 1.95 27.56 24.55 2.18 26.24 23.94 2.43 24.86 23.29 2.70 23.47 23.47 3.00 22.07 22.07 3.33 57 (13.9) 28.00 28.00 1.95 26.98 26.98 2.18 25.89 25.89 2.43 24.74 24.74 2.70 23.48 23.48 3.00 22.07 22.07 3.33
1000
72 (22.2) 34.88 18.05 2.01 33.32 17.49 2.23 31.66 16.90 2.48 29.96 16.30 2.76 28.11 15.65 3.06 26.06 14.95 3.38 67 (19.4) 31.98 22.49 2.01 30.53 21.91 2.23 29.00 21.31 2.48 27.40 20.68 2.75 25.69 20.03 3.05 23.80 19.31 3.38 62 (16.7) 29.44 26.90 2.00 28.16 26.29 2.23 26.81 26.81 2.48 25.62 25.62 2.75 24.28 24.28 3.05 22.79 22.79 3.38 57 (13.9) 29.10 29.10 2.00 28.01 28.01 2.23 26.85 26.85 2.48 25.62 25.62 2.75 24.28 24.28 3.05 22.79 22.79 3.38
1125
72 (22.2) 35.27 18.78 2.06 33.67 18.21 2.28 31.96 17.61 2.53 30.22 17.01 2.81 28.32 16.36 3.11 26.21 15.64 3.43 67 (19.4) 32.36 23.68 2.05 30.87 23.10 2.28 29.29 22.50 2.53 27.66 21.88 2.80 25.91 21.21 3.10 23.99 20.48 3.43 62 (16.7) 30.02 28.49 2.05 28.84 28.84 2.28 27.62 27.62 2.52 26.32 26.32 2.80 24.92 24.92 3.10 23.35 23.35 3.42 57 (13.9) 29.99 29.99 2.05 28.84 28.84 2.28 27.62 27.62 2.52 26.32 26.32 2.80 24.92 24.92 3.10 23.35 23.35 3.42
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CAP**3014A** 1.00 1.00
CAP**3017A** 1.00 1.00 CAP**3614A** 0.97 0.97 CAP**3617A** 1.01 1.01 CAP**3621A** 1.01 1.01
CNPF*3618A** 1.00 1.00
CNPH*3017A** 1.00 1.00 CNPH*3617A** 1.00 1.00
CNPV*3014A** 1.00 1.00 CNPV*3017A** 1.00 1.00 CNPV*3617A** 1.00 1.00 CNPV*3621A** 1.00 1.00
CSPH*3012A** 1.00 1.00 CSPH*3612A** 1.01 1.01
FE4AN(B,F)003 1.01 0.91 FE4AN(B,F)005 1.03 0.92
FE4ANF002 1.00 0.94
FE5ANB004 1.04 0.92
FF1ENP030 0.99 0.99 FF1ENP036 1.01 1.01
FV4BN(B,F)003 1.01 0.91 FV4BN(B,F)005 1.03 0.92
FV4BNF002 1.00 0.94
FX4CN(B,F)036 1.01 0.97
FX4CNF030 1.01 0.94
FY4ANF030 0.99 0.99 FY4ANF036 1.00 1.00
CAP**3014A** 0.99 0.93 58CV(A,X)070--- 12 CAP**3614A** 0.99 0.93 58CV(A,X)070--- 12
CNPH*3017A** 0.99 0.93 58CV(A,X)070--- 12 CNPH*3617A** 0.99 0.93 58CV(A,X)070--- 12
CNPV*3014A** 0.99 0.93 58CV(A,X)070--- 12
CSPH*3012A** 1.00 0.94 58CV(A,X)070 --- 12 CSPH*3612A** 1.00 0.94 58CV(A,X)070 --- 12
CAP**3017A** 0.99 0.93 58CV(A,X)090--- 16 CAP**3617A** 1.00 0.90 58CV(A,X)090--- 16
CNPH*3017A** 0.99 0.93 58CV(A,X)090--- 16 CNPH*3617A** 0.99 0.93 58CV(A,X)090--- 16
CNPV*3017A** 0.99 0.93 58CV(A,X)090--- 16
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*3617A** 0.99 0.93 58CV(A,X)090--- 16
CSPH*3012A** 1.00 0.94 58CV(A,X)090 --- 16 CSPH*3612A** 1.00 0.90 58CV(A,X)090 --- 16
CAP**3621A** 1.00 0.90 58CV(A,X)110--- 20
CNPH*3017A** 1.00 0.94 58CV(A,X)110--- 20 CNPH*3617A** 1.00 0.94 58CV(A,X)110--- 20
CNPV*3621A** 1.00 0.94 58CV(A,X)110--- 20
CSPH*3012A** 1.00 0.94 58CV(A,X)110 --- 20 CSPH*3612A** 1.00 0.90 58CV(A,X)110 --- 20
CNPH*3017A** 1.00 0.94 58CV(A,X)135--- 22 CNPH*3617A** 1.00 0.94 58CV(A,X)135--- 22
CSPH*3012A** 1.00 0.94 58CV(A,X)135 --- 22 CSPH*3612A** 1.00 0.90 58CV(A,X)135 --- 22
CNPH*3017A** 1.00 0.90 58CV(A,X)155--- 22 CNPH*3617A** 1.00 0.90 58CV(A,X)155--- 22
CSPH*3012A** 1.00 0.94 58CV(A,X)155 --- 22 CSPH*3612A** 1.00 0.90 58CV(A,X)155 --- 22
CAP**3017A** 1.01 0.91 58MEB040--- 12 CAP**3617A** 1.01 0.91 58MEB040--- 12
CNPH*3017A** 1.01 0.91 58MEB040--- 12 CNPH*3617A** 1.01 0.91 58MEB040--- 12
CNPV*3017A** 1.01 0.91 58MEB040--- 12 CNPV*3617A** 1.01 0.91 58MEB040--- 12
CSPH*3012A** 1.01 0.91 58MEB040--- 12 CSPH*3612A** 1.01 0.91 58MEB040--- 12
CAP**3017A** 1.01 0.91 58MEB060--- 12 CAP**3617A** 1.01 0.91 58MEB060--- 12
CNPH*3017A** 1.01 0.91 58MEB060--- 12 CNPH*3617A** 1.01 0.91 58MEB060--- 12
CNPV*3017A** 1.01 0.91 58MEB060--- 12 CNPV*3617A** 1.01 0.91 58MEB060--- 12
CSPH*3012A** 1.01 0.91 58MEB060--- 12 CSPH*3612A** 1.01 0.91 58MEB060--- 12
CAP**3017A** 1.01 0.91 58MEB080--- 12 CAP**3617A** 1.01 0.91 58MEB080--- 12
CNPH*3017A** 1.01 0.91 58MEB080--- 12 CNPH*3617A** 1.01 0.91 58MEB080--- 12
CNPV*3017A** 1.01 0.91 58MEB080--- 12 CNPV*3617A** 1.01 0.91 58MEB080--- 12
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CSPH*3012A** 1.01 0.91 58MEB080--- 12 CSPH*3612A** 1.01 0.91 58MEB080--- 12
CAP**3017A** 1.01 0.94 58MEB080--- 16 CAP**3617A** 1.01 0.91 58MEB080--- 16
CNPH*3017A** 1.01 0.94 58MEB080--- 16 CNPH*3617A** 1.01 0.94 58MEB080--- 16
CNPV*3017A** 1.01 0.94 58MEB080--- 16 CNPV*3617A** 1.01 0.94 58MEB080--- 16
CSPH*3012A** 1.01 0.94 58MEB080--- 16 CSPH*3612A** 1.01 0.91 58MEB080--- 16
CNPH*3017A** 0.99 0.93 58MV(B,C)040 --- 14 CNPH*3617A** 0.99 0.93 58MV(B,C)040 --- 14
CSPH*3012A** 0.99 0.93 58MV(B,C)040--- 14 CSPH*3612A** 1.00 0.94 58MV(B,C)040--- 14
CAP**3017A** 0.99 0.93 58MV(B,C)060--- 14 CAP**3617A** 0.99 0.93 58MV(B,C)060--- 14
CNPH*3017A** 0.99 0.93 58MV(B,C)060 --- 14 CNPH*3617A** 0.99 0.93 58MV(B,C)060 --- 14
CNPV*3017A** 0.99 0.93 58MV(B,C)060--- 14 CNPV*3617A** 0.99 0.93 58MV(B,C)060--- 14
CSPH*3012A** 0.99 0.93 58MV(B,C)060--- 14 CSPH*3612A** 1.00 0.90 58MV(B,C)060--- 14
CAP**3621A** 0.99 0.93 58MV(B,C)080--- 14
CNPH*3017A** 0.99 0.93 58MV(B,C)080 --- 14 CNPH*3617A** 0.99 0.93 58MV(B,C)080 --- 14
CNPV*3621A** 0.99 0.93 58MV(B,C)080--- 14
CSPH*3012A** 0.99 0.93 58MV(B,C)080--- 14 CSPH*3612A** 1.00 0.94 58MV(B,C)080--- 14
CAP**3621A** 1.00 0.94 58MV(B,C)080--- 20
CNPH*3017A** 0.99 0.93 58MV(B,C)080 --- 20 CNPH*3617A** 0.99 0.93 58MV(B,C)080 --- 20
CNPV*3621A** 0.99 0.93 58MV(B,C)080--- 20
CSPH*3012A** 1.00 0.94 58MV(B,C)080--- 20 CSPH*3612A** 1.00 0.90 58MV(B,C)080--- 20
CAP**3621A** 0.99 0.93 58MV(B,C)100--- 20
CNPH*3017A** 0.99 0.92 58MV(B,C)100 --- 20 CNPH*3617A** 0.99 0.92 58MV(B,C)100 --- 20
CNPV*3621A** 0.99 0.92 58MV(B,C)100--- 20
CSPH*3012A** 0.99 0.93 58MV(B,C)100--- 20
