DETAI LED COOLING CAPACITI ES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Tot a l Sens‡ Tot al Sens‡ To t al Sens‡ Tota l Sens‡ To tal Sens‡ To t al Sens‡
24ACB436A30 Outdoor Section With CAP**4221A** Indoor Section
1050
72 (22.2) 42.83 22.38 2.35 40.92 21.65 2.63 38.92 20.89 2.94 36.78 20.09 3.29 34.47 19.23 3.68 31.94 18.31 4.12 67 (19.4) 38.83 27.27 2.35 37.06 26.52 2.63 35.20 25.74 2.94 33.22 24.93 3.29 31.08 24.06 3.68 28.75 23.12 4.12 62 (16.7) 35.34 32.16 2.35 33.74 31.40 2.63 32.07 30.59 2.94 30.32 29.72 3.29 28.58 28.58 3.68 26.83 26.83 4.12 57 (13.9) 34.26 34.26 2.35 32.98 32.98 2.63 31.63 31.63 2.94 30.17 30.17 3.29 28.58 28.58 3.68 26.83 26.83 4.12
1200
72 (22.2) 43.66 23.46 2.40 41.67 22.71 2.68 39.58 21.94 2.99 37.36 21.12 3.34 34.96 20.26 3.73 32.33 19.32 4.17 67 (19.4) 39.58 28.97 2.40 37.74 28.21 2.68 35.80 27.42 2.99 33.75 26.59 3.34 31.55 25.71 3.73 29.14 24.76 4.17 62 (16.7) 36.18 34.48 2.40 34.56 33.67 2.68 32.87 32.87 2.99 31.35 31.35 3.34 29.67 29.67 3.73 27.80 27.80 4.17 57 (13.9) 35.72 35.72 2.40 34.36 34.36 2.68 32.91 32.91 2.99 31.36 31.36 3.34 29.67 29.67 3.73 27.80 27.80 4.17
1350
72 (22.2) 44.27 24.46 2.45 42.22 23.70 2.73 40.06 22.91 3.05 37.77 22.09 3.40 35.31 21.21 3.79 32.61 20.26 4.22 67 (19.4) 40.14 30.57 2.45 38.24 29.80 2.73 36.25 29.01 3.04 34.15 28.17 3.39 31.89 27.28 3.78 29.44 26.29 4.22 62 (16.7) 36.97 36.59 2.45 35.49 35.49 2.73 33.97 33.97 3.04 32.33 32.33 3.39 30.56 30.56 3.78 28.59 28.59 4.22 57 (13.9) 36.94 36.94 2.45 35.50 35.50 2.73 33.97 33.97 3.04 32.34 32.34 3.39 30.56 30.56 3.78 28.60 28.60 4.22
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CAP**4221A** 1.00 1.00
CAP**3614A** 0.96 0.96 CAP**3617A** 0.99 1.03 CAP**3621A** 0.99 1.03 CAP**4224A** 1.00 1.00
CNPF*3618A** 0.99 1.03
CNPH*3617A** 0.99 1.03 CNPH*4221A** 0.98 0.98
CNPV*3617A** 0.99 1.00 CNPV*3621A** 0.99 1.03 CNPV*4217A** 1.00 1.00 CNPV*4221A** 0.98 0.98
CSPH*3612A** 0.99 0.99 CSPH*4212A** 0.98 0.98
FE4AN(B,F)003 0.99 0.91 FE4AN(B,F)005 1.03 0.95
FE4ANB006 1.03 0.92
FE4ANF002 0.98 0.94 FF1ENP036 0.98 0.98
FV4BN(B,F)003 0.99 0.91 FV4BN(B,F)005 1.02 0.94
FV4BNB006 1.03 0.92
FV4BNF002 0.98 0.94
FX4CN(B,F)036 1.01 0.97 FX4CN(B,F)042 1.02 0.94
FY4ANF036 0.97 1.01 FY4ANF042 1.01 1.01
CAP**3614A** 0.95 0.91 58CV(A,X)070--- 12
CNPH*3617A** 0.98 0.94 58CV(A,X)070--- 12 CNPH*4221A** 0.98 0.91 58CV(A,X)070--- 12
CNPV*3617A** 0.98 0.94 58CV(A,X)070--- 12
CSPH*3612A** 0.98 0.94 58CV(A,X)070 --- 12 CSPH*4212A** 0.98 0.94 58CV(A,X)070 --- 12
CAP**3617A** 0.98 0.94 58CV(A,X)090--- 16
CNPV*3617A** 0.98 0.94 58CV(A,X)090--- 16 CNPV*4217A** 0.99 0.95 58CV(A,X)090--- 16
CAP**3621A** 0.98 0.91 58CV(A,X)110--- 20 CAP**4221A** 0.99 0.91 58CV(A,X)110--- 20
CNPV*3621A** 0.98 0.94 58CV(A,X)110--- 20
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*4221A** 0.99 0.91 58CV(A,X)110--- 20
CAP**4224A** 0.99 0.91 58CV(A,X)135--- 22
CNPH*4221A** 0.98 0.91 58CV(A,X)135--- 22 CNPH*4221A** 0.98 0.91 58CV(A,X)155--- 22
CAP**3617A** 0.99 0.95 58MEB040--- 12
CNPH*3617A** 0.98 0.94 58MEB040--- 12 CNPH*4221A** 0.99 0.95 58MEB040--- 12
CNPV*3617A** 0.98 0.94 58MEB040--- 12 CNPV*4217A** 0.99 0.95 58MEB040--- 12
CSPH*3612A** 0.99 0.95 58MEB040--- 12 CSPH*4212A** 0.99 0.95 58MEB040--- 12
CAP**3617A** 0.99 0.95 58MEB060--- 12
CNPH*3617A** 0.98 0.94 58MEB060--- 12 CNPH*4221A** 0.99 0.95 58MEB060--- 12
CNPV*3617A** 0.98 0.94 58MEB060--- 12 CNPV*4217A** 0.99 0.95 58MEB060--- 12
CSPH*3612A** 0.99 0.95 58MEB060--- 12 CSPH*4212A** 0.99 0.95 58MEB060--- 12
CAP**3617A** 0.99 0.95 58MEB080--- 12
CNPH*3617A** 0.98 0.94 58MEB080--- 12 CNPH*4221A** 0.99 0.95 58MEB080--- 12
CNPV*3617A** 0.98 0.94 58MEB080--- 12 CNPV*4217A** 0.99 0.95 58MEB080--- 12
CSPH*3612A** 0.99 0.95 58MEB080--- 12 CSPH*4212A** 0.99 0.95 58MEB080--- 12
CAP**3617A** 0.99 0.95 58MEB080--- 16
CNPH*3617A** 0.98 0.97 58MEB080--- 16 CNPH*4221A** 0.99 0.95 58MEB080--- 16
CNPV*3617A** 0.98 0.97 58MEB080--- 16 CNPV*4217A** 0.99 0.95 58MEB080--- 16
CSPH*3612A** 0.99 0.95 58MEB080--- 16 CSPH*4212A** 0.99 0.95 58MEB080--- 16
CAP**3621A** 0.99 0.95 58MEB100--- 20 CAP**4221A** 0.99 0.95 58MEB100--- 20
CNPH*3617A** 0.98 0.94 58MEB100--- 20 CNPH*4221A** 0.99 0.95 58MEB100--- 20
CNPV*3621A** 0.98 0.94 58MEB100--- 20 CNPV*4221A** 0.99 0.95 58MEB100--- 20
CSPH*3612A** 0.99 0.95 58MEB100--- 20
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CSPH*4212A** 0.99 0.95 58MEB100--- 20
CAP**4224A** 0.98 0.94 58MV(B,C)040--- 14
CNPH*3617A** 0.97 0.93 58MV(B,C)040 --- 14 CNPH*4221A** 0.98 0.91 58MV(B,C)040 --- 14
CSPH*3612A** 0.98 0.94 58MV(B,C)040--- 14 CSPH*4212A** 0.98 0.94 58MV(B,C)040--- 14
CAP**3617A** 0.98 0.94 58MV(B,C)060--- 14
CNPV*3617A** 0.98 0.94 58MV(B,C)060--- 14 CNPV*4217A** 1.00 0.96 58MV(B,C)060--- 14
CAP**3621A** 0.98 0.94 58MV(B,C)080--- 14 CAP**4221A** 0.98 0.94 58MV(B,C)080--- 14
CNPV*3621A** 0.97 0.93 58MV(B,C)080--- 14 CNPV*4221A** 0.98 0.91 58MV(B,C)080--- 14
CAP**3621A** 0.98 0.94 58MV(B,C)080--- 20 CAP**4221A** 0.99 0.95 58MV(B,C)080--- 20 CAP**3621A** 0.98 0.91 58MV(B,C)100--- 20 CAP**4221A** 0.99 0.95 58MV(B,C)100--- 20 CAP**4224A** 0.99 0.91 58MV(B,C)120--- 20
CSPH*4212A** 0.98 0.94 58MV(B,C)120--- 20
CAP**3614A** 0.98 0.98 58PH*045--- 08
CNPH*3617A** 0.98 0.98 58PH*045--- 08 CNPH*4221A** 0.99 0.97 58PH*045--- 08
CSPH*3612A** 1.00 0.98 58PH*045--- 08 CSPH*4212A** 1.01 0.99 58PH*045--- 08
CAP**3617A** 0.98 0.97 58PH*070--- 16
CNPH*3617A** 0.98 0.96 58PH*070--- 16 CNPH*4221A** 0.99 0.95 58PH*070--- 16
CNPV*3617A** 0.98 0.96 58PH*070--- 16 CNPV*4217A** 0.99 0.98 58PH*070--- 16
CSPH*3612A** 1.00 0.96 58PH*070--- 16 CSPH*4212A** 1.01 0.97 58PH*070--- 16
CAP**3621A** 0.99 0.94 58PH*090--- 16 CAP**4221A** 1.00 0.92 58PH*090--- 16
CNPH*3617A** 0.98 0.94 58PH*090--- 16 CNPH*4221A** 0.99 0.92 58PH*090--- 16
CNPV*3621A** 0.98 0.94 58PH*090--- 16 CNPV*4221A** 0.99 0.92 58PH*090--- 16
CSPH*3612A** 1.00 0.92 58PH*090--- 16 CSPH*4212A** 1.01 0.93 58PH*090--- 16
