DETAI LED COOLING CAPACITI ES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Tot a l Sens‡ Tot al Sens‡ To t al Sens‡ Tota l Sens‡ To tal Sens‡ To t al Sens‡
24ACB442A30 Outdoor Section With CAP**4821A* Indoor Section
1225
72 (22.2) 51.84 27.33 2.27 49.61 26.48 2.54 47.23 25.58 2.84 44.68 24.63 3.17 41.93 23.62 3.54 38.86 22.51 3.93 67 (19.4) 47.48 33.63 2.26 45.42 32.76 2.53 43.24 31.85 2.83 40.90 30.89 3.16 38.37 29.87 3.53 35.58 28.75 3.92 62 (16.7) 43.52 39.88 2.25 41.66 38.99 2.52 39.71 38.06 2.82 37.64 37.03 3.15 35.60 35.60 3.52 33.47 33.47 3.92 57 (13.9) 42.32 42.32 2.24 40.83 40.83 2.52 39.23 39.23 2.82 37.49 37.49 3.15 35.60 35.60 3.52 33.47 33.47 3.92
1400
72 (22.2) 52.87 28.72 2.28 50.55 27.86 2.55 48.06 26.94 2.85 45.41 25.98 3.18 42.56 24.95 3.55 39.39 23.83 3.94 67 (19.4) 48.46 35.83 2.27 46.31 34.94 2.54 44.04 34.02 2.84 41.60 33.04 3.17 39.00 32.01 3.54 36.11 30.87 3.93 62 (16.7) 44.62 42.86 2.26 42.72 41.91 2.53 40.81 40.81 2.83 38.97 38.97 3.16 36.95 36.95 3.53 34.67 34.67 3.93 57 (13.9) 44.15 44.15 2.25 42.54 42.54 2.53 40.83 40.83 2.83 38.97 38.97 3.16 36.95 36.95 3.53 34.67 34.67 3.93
1575
72 (22.2) 53.67 30.04 2.29 51.27 29.16 2.56 48.70 28.24 2.86 45.98 27.26 3.19 43.04 26.23 3.55 39.79 25.09 3.95 67 (19.4) 49.22 37.92 2.27 47.00 37.03 2.55 44.66 36.10 2.85 42.17 35.11 3.18 39.49 34.06 3.54 36.54 32.88 3.94 62 (16.7) 45.61 45.61 2.27 43.95 43.95 2.54 42.14 42.14 2.84 40.17 40.17 3.17 38.04 38.04 3.54 35.64 35.64 3.94 57 (13.9) 45.65 45.65 2.27 43.95 43.95 2.54 42.14 42.14 2.84 40.18 40.18 3.17 38.04 38.04 3.54 35.64 35.64 3.94
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CAP**4821A** 1.00 1.00
CAP**4221A** 0.99 1.01 CAP**4224A** 0.99 1.01 CAP**4817A** 1.00 1.00 CAP**4824A** 1.00 1.00
CNPF*4818A** 1.00 1.00
CNPH*4221A** 0.99 1.01 CNPH*4821A** 1.00 1.00
CNPV*4217A** 1.00 1.00 CNPV*4221A** 0.99 1.01 CNPV*4821A** 1.00 1.00 CNPV*4824A** 1.00 1.00
CSPH*4212A** 1.00 1.00 CSPH*4812A** 1.00 1.00
FE4AN(B,F)003 0.99 0.95 FE4AN(B,F)005 1.03 0.95
FE4ANB006 1.03 0.91 FE5ANB004 1.03 0.91
FV4BN(B,F)003 0.99 0.95 FV4BN(B,F)005 1.03 0.95
FV4BNB006 1.03 0.91
FX4CN(B,F)042 1.01 0.97 FX4CN(B,F)048 1.04 0.96
FY4ANF042 1.00 1.03 FY4ANF048 1.01 1.04
CNPH*4221A** 0.98 0.98 58CV(A,X)070--- 12 CNPH*4821A** 1.00 0.98 58CV(A,X)070--- 12
CSPH*4212A** 0.99 0.97 58CV(A,X)070 --- 12 CSPH*4812A** 1.00 0.98 58CV(A,X)070 --- 12
CAP**4817A** 1.00 0.96 58CV(A,X)090--- 16
CNPH*4221A** 0.99 0.97 58CV(A,X)090--- 16 CNPH*4821A** 1.00 0.96 58CV(A,X)090--- 16
CNPV*4217A** 0.99 0.97 58CV(A,X)090--- 16
CSPH*4212A** 0.99 0.95 58CV(A,X)090 --- 16 CSPH*4812A** 1.00 0.96 58CV(A,X)090 --- 16
CAP**4221A** 0.99 0.95 58CV(A,X)110--- 20 CAP**4821A** 1.00 0.96 58CV(A,X)110--- 20
CNPH*4221A** 0.99 0.97 58CV(A,X)110--- 20 CNPH*4821A** 1.00 0.96 58CV(A,X)110--- 20
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*4221A** 0.99 0.97 58CV(A,X)110--- 20 CNPV*4821A** 1.00 0.96 58CV(A,X)110--- 20
CSPH*4212A** 0.99 0.97 58CV(A,X)110 --- 20 CSPH*4812A** 1.00 0.96 58CV(A,X)110 --- 20
CAP**4224A** 0.99 0.95 58CV(A,X)135--- 22 CAP**4824A** 1.00 0.96 58CV(A,X)135--- 22
CNPH*4221A** 0.99 0.95 58CV(A,X)135--- 22 CNPH*4821A** 1.00 0.96 58CV(A,X)135--- 22
CNPV*4824A** 1.00 0.96 58CV(A,X)135--- 22
CSPH*4212A** 0.99 0.95 58CV(A,X)135 --- 22 CSPH*4812A** 1.00 0.96 58CV(A,X)135 --- 22
CAP**4224A** 0.99 0.95 58CV(A,X)155--- 22 CAP**4824A** 1.00 0.96 58CV(A,X)155--- 22
CNPH*4221A** 0.99 0.95 58CV(A,X)155--- 22 CNPH*4821A** 1.00 0.92 58CV(A,X)155--- 22
CNPV*4824A** 1.00 0.96 58CV(A,X)155--- 22
CSPH*4212A** 0.99 0.95 58CV(A,X)155 --- 22 CSPH*4812A** 1.00 0.92 58CV(A,X)155 --- 22
CAP**4817A** 1.00 0.98 58MEB080--- 16
CNPH*4221A** 0.99 0.97 58MEB080--- 16 CNPH*4821A** 1.00 0.98 58MEB080--- 16
CNPV*4217A** 0.99 0.97 58MEB080--- 16 CNPV*4821A** 1.00 0.96 58MEB080--- 16
CSPH*4212A** 1.00 0.98 58MEB080--- 16 CSPH*4812A** 1.00 0.98 58MEB080--- 16
CAP**4221A** 0.99 0.95 58MEB100--- 20 CAP**4821A** 1.00 0.96 58MEB100--- 20
CNPH*4221A** 0.99 0.97 58MEB100--- 20 CNPH*4821A** 1.00 0.96 58MEB100--- 20
CNPV*4221A** 0.99 0.97 58MEB100--- 20 CNPV*4821A** 1.00 0.96 58MEB100--- 20
CSPH*4212A** 0.99 0.95 58MEB100--- 20 CSPH*4812A** 1.00 0.96 58MEB100--- 20
CAP**4224A** 1.00 0.96 58MEB120--- 20 CAP**4824A** 1.00 0.96 58MEB120--- 20
CNPH*4221A** 0.99 0.95 58MEB120--- 20 CNPH*4821A** 1.00 0.96 58MEB120--- 20
CNPV*4824A** 1.00 0.96 58MEB120--- 20
CSPH*4212A** 1.00 0.96 58MEB120--- 20
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CSPH*4812A** 1.00 0.96 58MEB120--- 20
CAP**4224A** 0.98 0.96 58MV(B,C)040--- 14 CAP**4824A** 0.99 0.97 58MV(B,C)040--- 14
CNPH*4221A** 0.98 0.98 58MV(B,C)040 --- 14 CNPH*4821A** 0.99 0.97 58MV(B,C)040 --- 14
CNPV*4824A** 0.99 0.97 58MV(B,C)040--- 14
CSPH*4212A** 0.98 0.96 58MV(B,C)040--- 14 CSPH*4812A** 1.00 0.98 58MV(B,C)040--- 14
CAP**4817A** 1.00 0.98 58MV(B,C)060--- 14
CNPH*4221A** 0.98 0.96 58MV(B,C)060 --- 14 CNPH*4821A** 1.00 0.96 58MV(B,C)060 --- 14
CNPV*4217A** 1.00 0.98 58MV(B,C)060--- 14
CSPH*4212A** 0.98 0.96 58MV(B,C)060--- 14 CSPH*4812A** 1.00 0.98 58MV(B,C)060--- 14
CAP**4221A** 0.98 0.96 58MV(B,C)080--- 14 CAP**4821A** 0.99 0.97 58MV(B,C)080--- 14
CNPH*4221A** 0.98 0.98 58MV(B,C)080 --- 14 CNPH*4821A** 0.99 0.97 58MV(B,C)080 --- 14
CNPV*4221A** 0.98 0.98 58MV(B,C)080--- 14 CNPV*4821A** 0.99 0.97 58MV(B,C)080--- 14
CSPH*4212A** 0.98 0.96 58MV(B,C)080--- 14 CSPH*4812A** 1.00 0.98 58MV(B,C)080--- 14
CAP**4221A** 0.98 0.96 58MV(B,C)080--- 20 CAP**4821A** 0.99 0.97 58MV(B,C)080--- 20
CNPH*4221A** 0.98 0.96 58MV(B,C)080 --- 20 CNPH*4821A** 0.99 0.97 58MV(B,C)080 --- 20
CNPV*4221A** 0.98 0.96 58MV(B,C)080--- 20 CNPV*4821A** 0.99 0.97 58MV(B,C)080--- 20
CSPH*4212A** 0.98 0.96 58MV(B,C)080--- 20 CSPH*4812A** 1.00 0.98 58MV(B,C)080--- 20
CAP**4221A** 0.98 0.94 58MV(B,C)100--- 20 CAP**4821A** 0.99 0.95 58MV(B,C)100--- 20
CNPH*4221A** 0.98 0.96 58MV(B,C)100 --- 20 CNPH*4821A** 0.99 0.95 58MV(B,C)100 --- 20
CNPV*4221A** 0.98 0.96 58MV(B,C)100--- 20 CNPV*4821A** 0.99 0.95 58MV(B,C)100--- 20
CSPH*4212A** 0.98 0.96 58MV(B,C)100--- 20 CSPH*4812A** 1.00 0.96 58MV(B,C)100--- 20
CAP**4224A** 0.98 0.96 58MV(B,C)120--- 20
