DETAI LED COOLING CAPACITI ES# (CONTINUED)

EVAPORATOR AIR

CONDENSER ENTERING AIR TEMPERATURES ° F (° C)

75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)

CFM

EWB

°F(°C)

Capacity MBtuh

Tot a l

Sys.

KW**

Capacity MBtuh

Tot a l

Sys.

KW**

Capacity MBtuh

Tot a l

Sys.

KW**

Capacity MBtuh

Tot a l

Sys.

KW**

Capacity MBtuh

Tot a l

Sys.

KW**

Capacity MBtuh

Tot a l

Sys.

KW**

Tot a l Sens‡ Tot al Sens‡ To t al Sens‡ Tota l Sens‡ To tal Sens‡ To t al Sens‡

24ACB460A30 Outdoor Section With CAP**6024A** Indoor Section

1750

72 (22.2) 70.52 37.08 3.97 67.20 35.81 4.38 63.70 34.48 4.83 59.99 33.10 5.32 55.97 31.62 5.86 51.51 30.01 6.45

67 (19.4) 64.33 45.47 3.92 61.31 44.20 4.33 58.13 42.87 4.78 54.75 41.49 5.27 51.12 40.02 5.82 47.11 38.42 6.40

62 (16.7) 58.81 53.84 3.87 56.12 52.55 4.28 53.31 51.19 4.73 50.40 49.71 5.23 47.55 47.55 5.78 44.50 44.50 6.38

57 (13.9) 57.17 57.17 3.86 55.01 55.01 4.27 52.72 52.72 4.73 50.25 50.25 5.23 47.55 47.55 5.78 44.50 44.50 6.38

2000

72 (22.2) 71.76 38.86 4.07 68.29 37.57 4.48 64.63 36.22 4.93 60.76 34.81 5.43 56.59 33.31 5.96 51.97 31.67 6.55

67 (19.4) 65.49 48.34 4.02 62.33 47.04 4.43 59.00 45.69 4.88 55.50 44.28 5.37 51.73 42.78 5.92 47.58 41.13 6.50

62 (16.7) 60.13 57.72 3.98 57.39 56.32 4.38 54.66 54.66 4.84 52.02 52.02 5.34 49.12 49.12 5.89 45.84 45.84 6.48

57 (13.9) 59.48 59.48 3.97 57.15 57.15 4.38 54.68 54.68 4.84 52.03 52.03 5.34 49.12 49.12 5.89 45.85 45.85 6.48

2250

72 (22.2) 72.67 40.54 4.17 69.08 39.23 4.58 65.29 37.86 5.03 61.30 36.43 5.52 57.00 34.90 6.06 52.25 33.24 6.64

67 (19.4) 66.34 51.06 4.12 63.07 49.75 4.53 59.64 48.38 4.98 56.04 46.94 5.47 52.17 45.40 6.01 47.92 43.68 6.60

62 (16.7) 61.32 61.32 4.08 58.90 58.90 4.49 56.27 56.27 4.95 53.45 53.45 5.45 50.38 50.38 6.00 46.91 46.91 6.59

57 (13.9) 61.37 61.37 4.08 58.90 58.90 4.49 56.27 56.27 4.95 53.46 53.46 5.45 50.38 50.38 6.00 46.92 46.92 6.59

COOLING INDOOR

MODEL

CAPACITY POWER FURNACE MODEL

*CAP**6024A** 1.00 1.00

CAP**6021A** 0.98 1.03

CNPH*6024A** 0.98 0.98

CNPV*6024A** 0.98 0.98

CSPH*6012A** 0.98 0.98

FE4ANB006 1.00 0.96

FV4BNB006 1.00 0.96

FX4CN(B,F)060 1.01 1.01

FY4ANB060 1.00 1.04

CNPH*6024A** 0.97 0.97 58CV(A,X)110--- 20

CNPV*6024A** 0.97 0.97 58CV(A,X)110--- 20

CSPH*6012A** 0.97 0.97 58CV(A,X)110 --- 20

CAP**6024A** 0.98 0.98 58CV(A,X)135--- 22

CNPH*6024A** 0.97 0.97 58CV(A,X)135--- 22

CNPV*6024A** 0.97 0.97 58CV(A,X)135--- 22

CSPH*6012A** 0.97 0.97 58CV(A,X)135 --- 22

COOLING INDOOR

MODEL

CAPACITY POWER FURNACE MODEL

CAP**6024A** 0.98 0.98 58CV(A,X)155--- 22

CNPH*6024A** 0.98 0.98 58CV(A,X)155--- 22

CNPV*6024A** 0.98 0.98 58CV(A,X)155--- 22

CSPH*6012A** 0.98 0.98 58CV(A,X)155 --- 22

CNPH*6024A** 0.97 0.97 58MEB080--- 16

CSPH*6012A** 0.97 0.97 58MEB080--- 16

CAP**6021A** 0.97 0.97 58MEB100--- 20

CNPH*6024A** 0.97 0.97 58MEB100--- 20

CSPH*6012A** 0.97 0.97 58MEB100--- 20

CAP**6024A** 0.97 0.96 58MEB120--- 20

CNPH*6024A** 0.97 0.96 58MEB120--- 20

CNPV*6024A** 0.97 0.96 58MEB120--- 20

CSPH*6012A** 0.97 0.96 58MEB120--- 20

CAP**6021A** 0.94 0.94 58MV(B,C)080--- 20

CNPH*6024A** 0.94 0.94 58MV(B,C)080 --- 20

CSPH*6012A** 0.95 0.95 58MV(B,C)080--- 20

COOLING INDOOR

MODEL

CAPACITY POWER FURNACE MODEL

CNPH*6024A** 0.94 0.94 58MV(B,C)100 --- 20

CSPH*6012A** 0.95 0.95 58MV(B,C)100--- 20

CNPH*6024A** 0.94 0.94 58MV(B,C)120 --- 20

CNPV*6024A** 0.94 0.94 58MV(B,C)120--- 20

CSPH*6012A** 0.95 0.95 58MV(B,C)120--- 20

CAP**6021A** 0.97 0.96 58PH*090--- 16

CNPH*6024A** 0.97 0.97 58PH*090--- 16

CSPH*6012A** 0.97 0.96 58PH*090--- 16

CAP**6021A** 0.97 0.96 58PH*110--- 20

CNPH*6024A** 0.97 0.96 58PH*110--- 20

CSPH*6012A** 0.98 0.97 58PH*110--- 20

CAP**6024A** 0.97 0.96 58PH*135--- 20

CNPH*6024A** 0.97 0.96 58PH*135--- 20

CNPV*6024A** 0.97 0.96 58PH*135--- 20

CSPH*6012A** 0.97 0.96 58PH*135--- 20

See notes on page 29

{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted.

} Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh

(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80_F(27_C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F(27_C).

# Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240---94. If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may

occur.
