15
DETAI LED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Tota l Sens‡ Tota l Sens‡ Tota l Sens‡ To ta l Sens‡ Tota l Sens‡ Tot a l Sens‡
24ACB760A**30 HIGH Outdoor Section With CNPHP6124 Indoor Section
1500
57 (13.9) 54.27 54.27 3.61 52.74 52.74 3.98 50.95 50.95 4.38 49.05 49.05 4.82 46.81 46.81 5.30 44.25 44.25 5.83
62 (16.7) 57.18 48.11 3.64 55.08 47.35 4.01 52.75 46.48 4.40 50.22 45.51 4.83 47.39 44.39 5.31 44.31 44.31 5.84
63 (17.2)†† 58.34 39.49 3.65 56.17 38.66 4.02 53.77 37.73 4.41 50.96 36.64 4.84 48.16 35.56 5.32 44.84 34.30 5.84
67 (19.4) 63.05 41.02 3.70 60.68 40.18 4.07 58.06 39.24 4.47 55.17 38.22 4.90 51.93 37.06 5.38 48.34 35.79 5.90
72 (22.2) 69.52 33.78 3.78 66.88 32.88 4.15 63.98 31.88 4.55 60.75 30.78 4.98 57.17 29.57 5.46 53.18 28.23 5.99
1710
57 (13.9) 56.76 56.76 3.70 55.08 55.08 4.07 53.17 53.17 4.47 51.02 51.02 4.91 48.63 48.63 5.40 45.87 45.87 5.93
62 (16.7) 58.63 51.57 3.72 56.42 50.77 4.09 54.01 49.87 4.48 51.39 48.81 4.92 48.70 48.70 5.40 45.93 45.93 5.93
63 (17.2)†† 59.71 41.82 3.73 57.41 40.98 4.10 54.85 40.03 4.49 52.06 38.99 4.93 48.95 37.84 5.40 45.51 36.55 5.92
67 (19.4) 64.47 43.51 3.79 61.97 42.66 4.16 59.19 41.71 4.55 56.13 40.67 4.98 52.75 39.51 5.46 48.99 38.22 5.98
72 (22.2) 71.04 35.32 3.87 68.25 34.40 4.23 65.17 33.38 4.63 61.79 32.27 5.07 58.01 31.02 5.54 53.89 29.69 6.07
1835
57 (13.9) 58.06 58.06 3.76 56.29 56.29 4.13 54.30 54.30 4.53 52.08 52.08 4.97 49.55 49.55 5.45 46.68 46.68 5.98
62 (16.7) 59.38 53.53 3.77 57.14 52.72 4.14 54.70 51.76 4.53 52.14 52.14 4.97 49.58 49.58 5.45 46.74 46.74 5.98
63 (17.2)†† 60.37 43.15 3.78 58.00 42.29 4.15 55.37 41.34 4.54 52.51 40.30 4.97 49.24 39.10 5.44 45.83 37.85 5.96
67 (19.4) 65.16 44.93 3.84 62.57 44.07 4.20 59.71 43.12 4.60 56.59 42.08 5.03 53.13 40.91 5.50 49.31 39.62 6.03
72 (22.2) 71.76 36.19 3.92 68.89 35.26 4.28 65.74 34.24 4.68 62.28 33.12 5.11 58.42 31.86 5.59 54.21 30.52 6.11
2000
57 (13.9) 59.59 59.59 3.83 57.72 57.72 4.20 55.62 55.62 4.60 53.28 53.28 5.04 50.62 50.62 5.52 47.63 47.63 6.05
62 (16.7) 60.30 55.99 3.83 58.01 55.08 4.20 55.69 55.69 4.60 53.35 53.35 5.04 50.69 50.69 5.52 47.68 47.68 6.05
63 (17.2)†† 61.09 44.84 3.84 58.64 43.97 4.21 55.94 43.02 4.60 53.00 41.98 5.03 49.50 40.70 5.50 46.17 39.50 6.02
67 (19.4) 65.91 46.75 3.90 63.22 45.88 4.26 60.31 44.93 4.66 57.09 43.89 5.09 53.55 42.72 5.56 49.66 41.41 6.09
72 (22.2) 72.57 37.29 3.98 69.61 36.36 4.34 66.35 35.32 4.74 62.79 34.19 5.17 58.84 32.94 5.65 54.49 31.56 6.17
24ACB760A**30 LOW Outdoor Section With CNPHP6124 Indoor Section
1100
57 (13.9) 49.86 23.91 2.40 47.66 23.10 2.70 45.29 22.25 3.03 42.73 21.34 3.41 39.96 20.38 3.85 36.97 19.36 4.36
62 (16.7) 44.89 28.95 2.41 42.92 28.16 2.72 40.78 27.32 3.06 38.45 26.41 3.45 35.95 25.45 3.90 33.27 24.43 4.42
63 (17.2)†† 41.27 27.74 2.43 39.43 26.95 2.74 37.48 26.12 3.09 35.35 25.23 3.48 33.05 24.28 3.94 30.59 23.28 4.47
67 (19.4) 40.39 33.88 2.43 38.64 33.10 2.74 36.73 32.25 3.09 34.69 31.33 3.49 32.55 32.36 3.95 30.57 30.57 4.47
72 (22.2) 38.60 38.60 2.44 37.27 37.27 2.75 35.79 35.79 3.10 34.18 34.18 3.49 32.43 32.43 3.95 30.51 30.51 4.47
1250
57 (13.9) 51.05 25.10 2.43 48.73 24.28 2.72 46.25 23.41 3.05 43.54 22.47 3.43 40.66 21.49 3.87 37.55 20.44 4.38
62 (16.7) 46.00 30.83 2.44 43.91 30.02 2.74 41.67 29.15 3.08 39.23 28.22 3.47 36.62 27.24 3.91 33.83 26.20 4.44
63 (17.2)†† 42.33 29.50 2.45 40.40 28.69 2.76 38.35 27.84 3.11 36.05 26.90 3.50 33.72 25.95 3.96 31.15 24.92 4.49
67 (19.4) 41.54 36.44 2.45 39.68 35.60 2.76 37.75 34.70 3.11 35.78 35.78 3.50 33.89 33.89 3.95 31.81 31.81 4.47
72 (22.2) 40.50 40.50 2.46 39.05 39.05 2.77 37.46 37.46 3.11 35.73 35.73 3.50 33.84 33.84 3.95 31.76 31.76 4.47
1400
57 (13.9) 51.99 26.23 2.45 49.57 25.39 2.75 46.98 24.50 3.08 44.19 23.56 3.45 41.20 22.55 3.89 37.99 21.49 4.40
62 (16.7) 46.87 32.63 2.46 44.69 31.80 2.76 42.36 30.92 3.10 39.84 29.97 3.49 37.15 28.97 3.93 34.27 27.90 4.45
63 (17.2)†† 43.18 31.19 2.47 41.18 30.37 2.78 39.04 29.50 3.13 36.72 28.56 3.52 34.24 27.56 3.98 31.59 26.49 4.51
67 (19.4) 42.54 38.84 2.48 40.71 40.48 2.78 38.96 38.96 3.13 37.09 37.09 3.51 35.06 35.06 3.96 32.84 32.84 4.48
72 (22.2) 42.13 42.13 2.48 40.58 40.58 2.78 38.89 38.89 3.13 37.02 37.02 3.51 35.01 35.01 3.96 32.80 32.80 4.48
1500
57 (13.9) 52.50 26.95 2.47 50.03 26.11 2.76 47.39 25.21 3.09 44.54 24.25 3.47 41.49 23.24 3.90 38.22 22.17 4.41
62 (16.7) 47.35 33.80 2.48 45.12 32.96 2.78 42.74 32.06 3.12 40.18 31.10 3.50 37.44 30.08 3.95 34.52 28.99 4.47
63 (17.2)†† 43.66 32.29 2.49 41.61 31.45 2.80 39.42 30.56 3.14 37.05 29.60 3.53 34.53 28.59 3.99 31.85 27.50 4.52
67 (19.4) 43.23 43.01 2.49 41.55 41.55 2.80 39.79 39.79 3.14 37.85 37.85 3.52 35.74 35.74 3.97 33.45 33.45 4.48
72 (22.2) 43.11 43.11 2.49 41.49 41.49 2.80 39.73 39.73 3.14 37.79 37.79 3.52 35.69 35.69 3.97 33.40 33.40 4.48
{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
} Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh
(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree belo w 80_F(27_C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F(27_C).
# Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per AHRI standard 210/240---2008. If additional tubing length an d/or indoor unit is located above outdoor unit, a slight variation in capacity
may occur.
** System kw is total of indoor and outdoor unit kilowatts.
EWB — E ntering Wet Bulb
NOTE: When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
24ACB7
