14
DETAI LED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Tota l Sens‡ Tota l Sens‡ Tota l Sens‡ To ta l Sens‡ Tota l Sens‡ Tot a l Sens‡
24ACB748A**31 Outdoor Section With CNPV*6124A**+58CV(A,X)135--- 22 Indoor Section --- High
1200
57 (13.9) 47.30 47.30 2.91 44.22 44.22 3.23 41.02 41.02 3.61 37.80 37.80 4.04 34.62 34.62 4.56 31.52 31.52 5.16
62 (16.7) 50.25 41.83 2.93 46.59 39.45 3.25 42.79 37.01 3.62 39.01 34.60 4.05 35.32 32.24 4.56 31.77 29.95 5.17
63 (17.2)†† 51.23 34.57 2.93 47.48 32.43 3.25 43.59 30.24 3.63 39.71 28.08 4.06 35.92 25.98 4.57 32.25 23.96 5.17
67 (19.4) 55.28 35.82 2.95 51.21 33.62 3.27 47.04 31.41 3.65 42.87 29.21 4.09 38.78 27.06 4.60 34.83 25.00 5.21
72 (22.2) 60.74 29.68 2.97 56.26 27.68 3.30 51.68 25.68 3.68 47.07 23.68 4.12 42.67 21.79 4.65 37.97 19.81 5.24
1300
57 (13.9) 48.75 48.75 2.94 45.52 45.52 3.26 42.20 42.20 3.64 38.85 38.85 4.08 35.56 35.56 4.59 32.33 32.33 5.20
62 (16.7) 51.12 43.71 2.95 47.36 41.24 3.27 43.48 38.72 3.65 39.61 36.23 4.08 35.87 33.78 4.59 32.38 32.38 5.20
63 (17.2)†† 52.07 35.84 2.96 48.22 33.65 3.28 44.23 31.40 3.65 40.26 29.19 4.09 36.38 27.03 4.60 32.63 24.95 5.20
67 (19.4) 56.14 37.18 2.98 51.97 34.92 3.30 47.69 32.64 3.68 43.42 30.38 4.12 39.25 28.19 4.63 35.21 26.06 5.24
72 (22.2) 61.64 30.52 3.00 57.05 28.49 3.33 52.36 26.44 3.71 47.70 24.43 4.15 43.13 22.47 4.67 38.69 20.58 5.29
1355
57 (13.9) 49.48 49.48 2.96 46.20 46.20 3.28 42.80 42.80 3.66 39.39 39.39 4.09 36.03 36.03 4.61 32.74 32.74 5.22
62 (16.7) 51.56 44.72 2.97 47.74 42.20 3.29 43.82 39.65 3.66 39.92 37.10 4.10 36.17 34.58 4.61 32.79 32.79 5.22
63 (17.2)†† 52.48 36.53 2.97 48.57 34.30 3.30 44.54 32.02 3.67 40.53 29.78 4.10 36.60 27.60 4.62 32.81 25.49 5.22
67 (19.4) 56.56 37.91 2.99 52.33 35.62 3.32 48.00 33.31 3.69 43.69 31.01 4.13 39.47 28.79 4.65 35.39 26.63 5.26
72 (22.2) 62.08 30.97 3.01 57.42 28.92 3.34 52.68 26.85 3.72 47.97 24.82 4.17 43.35 22.84 4.69 38.88 20.92 5.31
1500
57 (13.9) 51.23 51.23 3.00 47.78 47.78 3.33 44.22 44.22 3.70 40.65 40.65 4.14 37.14 37.14 4.66 33.69 33.69 5.27
62 (16.7) 52.58 47.33 3.01 48.66 44.69 3.33 44.65 42.00 3.70 40.72 40.58 4.14 37.19 37.19 4.66 33.74 33.74 5.27
63 (17.2)†† 53.41 38.29 3.01 49.38 35.97 3.34 45.25 33.63 3.71 41.12 31.31 4.14 37.11 29.05 4.66 33.23 26.87 5.26
67 (19.4) 57.51 39.78 3.03 53.15 37.41 3.35 48.71 35.02 3.73 44.29 32.66 4.17 39.97 30.35 4.69 35.81 28.12 5.30
72 (22.2) 63.05 32.12 3.05 58.27 30.02 3.38 53.40 27.90 3.76 48.57 25.81 4.21 43.85 23.78 4.73 39.27 21.82 5.35
1600
57 (13.9) 52.31 52.31 3.03 48.75 48.75 3.35 45.10 45.10 3.73 41.42 41.42 4.17 37.81 37.81 4.69 34.28 34.28 5.30
62 (16.7) 53.20 49.06 3.03 49.23 46.33 3.36 45.22 44.88 3.73 41.48 41.48 4.17 37.86 37.86 4.69 34.32 34.32 5.30
63 (17.2)†† 53.95 39.47 3.04 49.85 37.11 3.36 45.65 34.71 3.73 41.47 32.34 4.17 37.40 30.03 4.68 33.47 27.80 5.29
67 (19.4) 58.05 41.04 3.05 53.63 38.62 3.38 49.12 36.18 3.76 44.64 33.76 4.20 40.26 31.41 4.72 36.04 29.12 5.33
72 (22.2) 63.61 32.89 3.07 58.75 30.75 3.40 53.81 28.60 3.79 48.91 26.48 4.23 44.12 24.41 4.76 39.49 22.42 5.38
1700
57 (13.9) 53.29 53.29 3.06 49.64 49.64 3.38 45.88 45.88 3.76 42.12 42.12 4.20 38.42 38.42 4.72 34.80 34.80 5.33
62 (16.7) 53.79 50.73 3.06 49.81 47.89 3.38 45.95 45.95 3.76 42.18 42.18 4.20 38.47 38.47 4.72 34.84 34.84 5.33
63 (17.2)†† 54.43 40.62 3.06 50.27 38.21 3.39 46.01 35.77 3.76 41.77 33.35 4.20 37.65 30.99 4.71 33.68 28.70 5.32
67 (19.4) 58.53 42.28 3.08 54.05 39.81 3.41 49.47 37.32 3.78 44.94 34.84 4.22 40.51 32.44 4.74 36.24 30.10 5.35
72 (22.2) 64.10 33.64 3.10 59.16 31.47 3.43 54.15 29.28 3.81 49.20 27.12 4.26 44.36 25.03 4.79 39.67 23.01 5.40
24ACB748A**31 Outdoor Section With CNPV*6124A**+58CV(A,X)135--- 22 Indoor Section --- Low
960
57 (13.9) 34.79 34.79 1.95 32.17 32.17 2.27 29.47 29.47 2.63 26.72 26.72 3.04 23.95 23.95 3.52 21.20 21.20 4.07
62 (16.7) 36.22 32.17 1.94 33.19 29.54 2.26 30.08 26.91 2.62 26.94 24.30 3.04 24.00 24.00 3.52 21.24 21.24 4.07
63 (17.2)†† 36.92 26.30 1.93 33.83 24.03 2.25 30.63 21.75 2.62 27.37 19.49 3.04 24.11 17.30 3.52 20.88 15.17 4.07
67 (19.4) 40.15 27.45 1.91 36.84 25.12 2.23 33.42 22.79 2.59 29.95 20.49 3.01 26.47 18.23 3.49 23.02 16.05 4.04
72 (22.2) 44.69 22.68 1.87 41.06 20.65 2.19 37.33 18.62 2.56 33.54 16.62 2.98 29.75 14.67 3.46 25.97 12.78 4.01
1010
57 (13.9) 35.48 35.48 1.95 32.81 32.81 2.27 30.04 30.04 2.63 27.23 27.23 3.05 24.40 24.40 3.52 21.59 21.59 4.07
62 (16.7) 36.64 33.15 1.94 33.58 30.45 2.26 30.44 27.75 2.63 27.30 27.20 3.04 24.45 24.45 3.52 21.63 21.63 4.07
63 (17.2)†† 37.32 26.98 1.94 34.18 24.66 2.26 30.94 22.33 2.62 27.63 20.03 3.04 24.33 17.79 3.52 21.07 15.62 4.08
67 (19.4) 40.58 28.18 1.91 37.22 25.80 2.23 33.76 23.42 2.60 30.24 21.06 3.02 26.71 18.76 3.50 23.22 16.53 4.05
72 (22.2) 45.14 23.15 1.87 41.47 21.09 2.20 37.68 19.02 2.57 33.84 16.99 2.99 29.99 15.01 3.47 26.17 13.10 4.02
1120
57 (13.9) 36.87 36.87 1.95 34.08 34.08 2.27 31.19 31.19 2.63 28.25 28.25 3.05 25.31 25.31 3.53 22.38 22.38 4.07
62 (16.7) 37.49 35.25 1.95 34.37 32.41 2.27 31.24 31.24 2.63 28.30 28.30 3.05 25.36 25.36 3.53 22.42 22.42 4.07
63 (17.2)†† 38.08 28.43 1.94 34.86 26.01 2.26 31.53 23.59 2.63 28.15 21.19 3.05 24.76 18.85 3.53 21.43 16.59 4.09
67 (19.4) 41.40 29.73 1.91 37.95 27.25 2.24 34.39 24.77 2.61 30.78 22.31 3.03 27.17 19.91 3.51 23.60 17.58 4.06
72 (22.2) 46.01 24.15 1.88 42.22 22.02 2.20 38.32 19.89 2.57 34.40 17.78 3.00 30.46 15.73 3.48 26.55 13.75 4.03
1280
57 (13.9) 38.62 38.62 1.96 35.67 35.67 2.28 32.63 32.63 2.64 29.54 29.54 3.06 26.44 26.44 3.53 23.35 23.35 4.08
62 (16.7) 38.70 38.62 1.95 35.73 35.73 2.27 32.68 32.68 2.64 29.59 29.59 3.06 26.48 26.48 3.53 23.39 23.39 4.08
63 (17.2)†† 38.98 30.46 1.95 35.66 27.91 2.28 32.23 25.35 2.64 28.75 22.82 3.07 25.29 20.35 3.55 21.88 17.94 4.10
67 (19.4) 42.34 31.94 1.93 38.79 29.29 2.25 35.13 26.67 2.62 31.42 24.07 3.04 27.71 21.52 3.52 24.06 19.04 4.07
72 (22.2) 47.00 25.53 1.89 43.09 23.30 2.22 39.09 21.07 2.59 35.04 18.88 3.01 30.99 16.73 3.49 26.97 14.66 4.04
1440
57 (13.9) 40.11 40.11 1.96 37.03 37.03 2.28 33.85 33.85 2.65 30.63 30.63 3.07 27.39 27.39 3.54 24.17 24.17 4.09
62 (16.7) 40.18 40.18 1.96 37.09 37.09 2.28 33.91 33.91 2.65 30.68 30.68 3.07 27.43 27.43 3.54 24.20 24.20 4.09
63 (17.2)†† 39.70 32.42 1.97 36.29 29.74 2.29 32.80 27.05 2.66 29.25 24.39 3.08 25.73 21.77 3.56 22.32 22.12 4.12
67 (19.4) 43.09 34.04 1.94 39.46 31.27 2.26 35.72 28.51 2.63 31.92 25.76 3.06 28.16 23.08 3.54 24.46 20.44 4.09
72 (22.2) 47.76 26.84 1.90 43.76 24.52 2.23 39.67 22.21 2.60 35.52 19.93 3.03 31.38 17.70 3.51 27.28 15.54 4.06
See notes on page 15
24ACB7
