13
DETAI LED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Capacity MBtuh
Tota l S ys .
KW**
Tota l Sens‡ Tota l Sens‡ Tota l Sens‡ To ta l Sens‡ Tota l Sens‡ Tot a l Sens‡
24ACB736A**31 Outdoor Section With CNPV*4821A**+58CV(A,X)090--- 16 Indoor Section --- High
900
57 (13.9) 35.84 35.84 2.28 33.31 33.31 2.47 30.78 30.78 2.70 28.23 28.23 2.96 25.63 25.63 3.26 22.99 22.99 3.58
62 (16.7) 38.02 31.58 2.30 35.06 29.75 2.49 32.11 27.93 2.72 29.14 26.10 2.97 26.15 24.26 3.26 23.16 22.40 3.58
63 (17.2)†† 38.77 26.12 2.30 35.74 24.49 2.50 32.71 22.86 2.72 29.66 21.22 2.98 26.58 19.58 3.27 23.48 17.94 3.58
67 (19.4) 41.84 27.07 2.33 38.59 25.41 2.52 35.31 23.74 2.74 32.02 22.07 3.00 28.69 20.39 3.29 25.34 18.71 3.60
72 (22.2) 46.07 22.49 2.37 42.48 20.99 2.56 38.88 19.49 2.77 35.25 17.98 3.03 31.59 16.46 3.31 27.88 14.95 3.63
975
57 (13.9) 36.91 36.91 2.30 34.29 34.29 2.50 31.67 31.67 2.73 29.01 29.01 2.99 26.31 26.31 3.28 23.57 23.57 3.60
62 (16.7) 38.68 32.98 2.32 35.66 31.09 2.51 32.63 29.20 2.74 29.60 27.31 2.99 26.56 25.39 3.28 23.61 23.61 3.60
63 (17.2)†† 39.40 27.07 2.32 36.30 25.40 2.52 33.20 23.73 2.74 30.07 22.04 3.00 26.93 20.36 3.28 23.76 18.68 3.60
67 (19.4) 42.51 28.10 2.35 39.17 26.38 2.54 35.82 24.67 2.76 32.44 22.95 3.02 29.04 21.23 3.30 25.62 19.50 3.62
72 (22.2) 46.76 23.13 2.40 43.10 21.60 2.58 39.41 20.07 2.79 35.69 18.53 3.04 31.95 16.98 3.33 28.17 15.43 3.64
1005
57 (13.9) 37.31 37.31 2.31 34.65 34.65 2.51 31.99 31.99 2.74 29.30 29.30 2.99 26.56 26.56 3.28 23.78 23.78 3.60
62 (16.7) 38.93 33.53 2.33 35.87 31.61 2.52 32.83 29.70 2.74 29.77 27.78 3.00 26.72 25.82 3.29 23.82 23.82 3.60
63 (17.2)†† 39.63 27.45 2.33 36.51 25.76 2.52 33.38 24.06 2.75 30.22 22.37 3.00 27.05 20.67 3.29 23.85 18.96 3.60
67 (19.4) 42.75 28.49 2.36 39.37 26.76 2.55 36.00 25.03 2.77 32.59 23.29 3.02 29.17 21.56 3.31 25.71 19.81 3.62
72 (22.2) 47.01 23.39 2.40 43.32 21.84 2.58 39.60 20.29 2.80 35.85 18.74 3.05 32.08 17.18 3.34 28.27 15.62 3.65
1200
57 (13.9) 39.58 39.58 2.37 36.72 36.72 2.56 33.84 33.84 2.79 30.92 30.92 3.04 27.97 27.97 3.33 24.98 24.98 3.65
62 (16.7) 40.28 36.94 2.38 37.11 34.86 2.57 33.98 32.74 2.79 30.97 30.97 3.04 28.01 28.01 3.33 25.01 25.01 3.65
63 (17.2)†† 40.84 29.78 2.38 37.56 27.98 2.57 34.29 26.19 2.79 31.00 24.39 3.04 27.69 22.59 3.33 24.38 20.78 3.64
67 (19.4) 44.00 30.99 2.41 40.46 29.14 2.59 36.93 27.31 2.81 33.39 25.47 3.07 29.82 23.62 3.35 26.24 21.77 3.66
72 (22.2) 48.33 24.94 2.45 44.46 23.32 2.63 40.57 21.70 2.84 36.66 20.07 3.09 32.73 18.44 3.38 28.78 16.81 3.69
1350
57 (13.9) 41.01 41.01 2.41 38.01 38.01 2.60 34.98 34.98 2.82 31.93 31.93 3.08 28.84 28.84 3.37 25.70 25.70 3.68
62 (16.7) 41.19 39.34 2.41 38.05 38.05 2.60 35.03 35.03 2.82 31.97 31.97 3.08 28.88 28.88 3.37 25.73 25.73 3.68
63 (17.2)†† 41.54 31.48 2.42 38.18 29.61 2.60 34.82 27.74 2.82 31.44 25.87 3.07 28.06 23.99 3.36 24.68 22.09 3.67
67 (19.4) 44.70 32.80 2.45 41.09 30.89 2.63 37.47 28.98 2.85 33.83 27.06 3.10 30.19 25.13 3.38 26.53 23.19 3.69
72 (22.2) 49.07 26.06 2.49 45.10 24.39 2.67 41.11 22.71 2.88 37.11 21.04 3.12 33.08 19.36 3.41 29.04 17.68 3.72
24ACB736A**31 Outdoor Section With CNPV*4821A**+58CV(A,X)090--- 16 Indoor Section --- Low
720
57 (13.9) 26.16 26.16 1.51 24.56 24.56 1.75 22.93 22.93 2.02 21.26 21.26 2.34 19.53 19.53 2.71 17.74 17.74 3.15
62 (16.7) 27.22 23.86 1.51 25.33 21.80 1.74 23.44 19.77 2.02 21.51 17.78 2.34 19.57 19.55 2.71 17.77 17.77 3.15
63 (17.2)†† 27.75 19.50 1.50 25.81 17.73 1.74 23.86 15.99 2.01 21.86 14.30 2.34 19.80 12.63 2.71 17.68 11.01 3.15
67 (19.4) 30.15 20.35 1.48 28.03 18.51 1.72 25.90 16.71 2.00 23.75 14.95 2.32 21.53 13.24 2.70 19.24 11.56 3.13
72 (22.2) 33.42 16.77 1.46 31.06 15.17 1.70 28.71 13.59 1.98 26.32 12.07 2.30 23.88 10.60 2.67 21.37 9.16 3.10
780
57 (13.9) 26.97 26.97 1.52 25.30 25.30 1.75 23.60 23.60 2.02 21.87 21.87 2.34 20.07 20.07 2.72 18.21 18.21 3.15
62 (16.7) 27.71 25.00 1.51 25.78 22.85 1.75 23.85 20.74 2.02 21.92 21.84 2.34 20.11 20.11 2.72 18.24 18.24 3.15
63 (17.2)†† 28.20 20.29 1.51 26.21 18.45 1.74 24.21 16.66 2.02 22.17 14.90 2.34 20.07 13.18 2.72 17.90 11.50 3.16
67 (19.4) 30.62 21.18 1.49 28.44 19.28 1.73 26.27 17.42 2.00 24.06 15.60 2.33 21.79 13.82 2.70 19.46 12.09 3.13
72 (22.2) 33.92 17.30 1.46 31.51 15.64 1.70 29.09 14.04 1.98 26.65 12.48 2.31 24.16 10.96 2.68 21.60 9.49 3.11
835
57 (13.9) 27.64 27.64 1.52 25.91 25.91 1.75 24.16 24.16 2.03 22.37 22.37 2.35 20.52 20.52 2.72 18.59 18.59 3.15
62 (16.7) 28.12 26.02 1.51 26.16 23.78 1.75 24.23 24.10 2.03 22.41 22.41 2.35 20.55 20.55 2.72 18.62 18.62 3.15
63 (17.2)†† 28.57 20.99 1.51 26.54 19.10 1.75 24.49 17.26 2.02 22.41 15.45 2.35 20.28 13.68 2.72 18.08 11.95 3.16
67 (19.4) 30.99 21.93 1.49 28.78 19.97 1.73 26.56 18.06 2.01 24.30 16.19 2.33 22.00 14.36 2.71 19.64 12.57 3.14
72 (22.2) 34.32 17.77 1.47 31.86 16.08 1.71 29.39 14.44 1.99 26.91 12.85 2.31 24.38 11.29 2.68 21.77 9.79 3.11
960
57 (13.9) 28.98 28.98 1.52 27.13 27.13 1.76 25.27 25.27 2.03 23.35 23.35 2.35 21.38 21.38 2.73 19.34 19.34 3.16
62 (16.7) 29.01 29.01 1.52 27.17 27.17 1.76 25.30 25.30 2.03 23.39 23.39 2.35 21.41 21.41 2.73 19.37 19.37 3.16
63 (17.2)†† 29.25 22.53 1.52 27.14 20.52 1.76 25.03 18.57 2.04 22.87 16.64 2.36 20.67 14.76 2.74 18.42 12.92 3.17
67 (19.4) 31.69 23.58 1.50 29.39 21.49 1.74 27.09 19.46 2.02 24.76 17.47 2.34 22.39 15.52 2.72 19.97 13.62 3.15
72 (22.2) 35.05 18.80 1.48 32.49 17.03 1.72 29.94 15.32 2.00 27.37 13.65 2.32 24.76 12.02 2.70 22.08 10.44 3.13
1080
57 (13.9) 30.06 30.06 1.53 28.11 28.11 1.77 26.14 26.14 2.04 24.13 24.13 2.36 22.07 22.07 2.74 19.93 19.93 3.17
62 (16.7) 30.11 30.11 1.53 28.15 28.15 1.77 26.18 26.18 2.04 24.16 24.16 2.36 22.10 22.10 2.74 19.96 19.96 3.17
63 (17.2)†† 29.77 23.95 1.53 27.60 21.84 1.77 25.42 19.77 2.05 23.22 17.74 2.37 20.98 15.75 2.75 18.70 13.78 3.19
67 (19.4) 32.21 25.10 1.51 29.85 22.90 1.75 27.49 20.76 2.03 25.11 18.66 2.36 22.70 16.60 2.73 20.24 14.57 3.17
72 (22.2) 35.58 19.75 1.49 32.95 17.90 1.73 30.34 16.12 2.01 27.70 14.38 2.34 25.03 12.68 2.71 22.29 11.04 3.14
See notes on page 15
