DETAI LED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Capacity MBtuh
Tota l
Sys.
KW**
Tota l Sens‡ To t al Sens‡ Tota l Sens‡ To t a l Sens‡ Tot a l Sens‡ To t al Sens‡
24ACB724A**31 Outdoor Section With CNPV*3117A**+58CV(A,X)090--- 16 Indoor Section --- Low
450
57 (13.9) 17.62 17.62 1.05 16.16 16.16 1.25 14.68 14.68 1.48 13.20 13.20 1.76 11.79 11.79 2.07 10.43 10.43 2.44 62 (16.7) 18.73 15.76 1.04 17.00 14.15 1.24 15.27 12.56 1.48 13.57 11.03 1.75 11.95 9.57 2.07 10.46 10.45 2.44
63 (17.2)†† 19.10 13.04 1.04 17.34 11.64 1.24 15.56 10.27 1.47 13.83 8.95 1.75 12.16 7.70 2.07 10.58 6.53 2.44
67 (19.4) 20.70 13.55 1.02 18.79 12.11 1.22 16.89 10.70 1.46 15.02 9.35 1.73 13.24 8.06 2.06 11.55 6.85 2.43 72 (22.2) 22.95 11.31 1.00 20.84 10.04 1.20 18.74 8.82 1.44 16.71 7.65 1.71 14.76 6.54 2.04 12.91 5.51 2.42
500
57 (13.9) 18.38 18.38 1.05 16.84 16.84 1.25 15.28 15.28 1.48 13.74 13.74 1.75 12.25 12.25 2.07 10.84 10.84 2.44 62 (16.7) 19.20 16.75 1.04 17.41 15.05 1.24 15.63 13.38 1.48 13.90 11.76 1.75 12.28 12.28 2.07 10.85 10.85 2.44
63 (17.2)†† 19.56 13.72 1.04 17.73 12.26 1.24 15.90 10.83 1.48 14.11 9.45 1.75 12.40 8.15 2.07 10.78 6.92 2.44
67 (19.4) 21.19 14.29 1.02 19.21 12.78 1.22 17.25 11.30 1.46 15.33 9.89 1.74 13.49 8.54 2.06 11.76 7.27 2.44 72 (22.2) 23.47 11.79 1.00 21.29 10.47 1.20 19.13 9.20 1.44 17.03 7.99 1.72 15.02 6.85 2.05 13.12 5.78 2.43
550
57 (13.9) 19.06 19.06 1.05 17.44 17.44 1.25 15.81 15.81 1.48 14.21 14.21 1.75 12.66 12.66 2.07 11.19 11.19 2.44 62 (16.7) 19.60 17.71 1.04 17.77 15.93 1.24 15.96 14.17 1.48 14.23 14.23 1.75 12.68 12.68 2.07 11.21 11.21 2.45
63 (17.2)†† 19.94 14.38 1.04 18.06 12.86 1.24 16.18 11.37 1.48 14.34 9.94 1.75 12.59 8.58 2.08 10.94 7.29 2.45
67 (19.4) 21.60 15.00 1.02 19.57 13.42 1.22 17.55 11.89 1.46 15.58 10.42 1.74 13.70 9.01 2.06 11.93 7.68 2.44 72 (22.2) 23.90 12.24 1.00 21.66 10.89 1.20 19.44 9.57 1.44 17.29 8.32 1.72 15.24 7.14 2.05 13.30 6.04 2.43
600
57 (13.9) 19.66 19.66 1.05 17.98 17.98 1.25 16.28 16.28 1.48 14.62 14.62 1.75 13.02 13.02 2.08 11.50 11.50 2.45 62 (16.7) 19.96 18.65 1.04 18.11 16.78 1.24 16.31 16.31 1.48 14.65 14.65 1.75 13.04 13.04 2.08 11.52 11.52 2.45
63 (17.2)†† 20.26 15.03 1.04 18.33 13.45 1.24 16.41 11.90 1.48 14.54 10.42 1.76 12.76 9.00 2.08 11.08 7.67 2.45
67 (19.4) 21.94 15.69 1.03 19.86 14.06 1.23 17.80 12.47 1.46 15.79 10.93 1.74 13.88 9.47 2.07 12.08 8.09 2.45 72 (22.2) 24.26 12.68 1.00 21.96 11.29 1.20 19.70 9.94 1.44 17.50 8.65 1.72 15.41 7.44 2.06 13.44 6.30 2.44
650
57 (13.9) 20.20 20.20 1.05 18.46 18.46 1.25 16.71 16.71 1.48 15.00 15.00 1.76 13.35 13.35 2.08 11.78 11.78 2.45 62 (16.7) 20.31 19.56 1.05 18.49 18.49 1.25 16.74 16.74 1.48 15.02 15.02 1.76 13.37 13.37 2.08 11.80 11.80 2.45
63 (17.2)†† 20.54 15.66 1.05 18.58 14.03 1.25 16.62 12.42 1.48 14.72 10.89 1.76 12.90 9.42 2.09 11.21 8.03 2.46
67 (19.4) 22.24 16.37 1.03 20.11 14.68 1.23 18.01 13.03 1.47 15.97 11.44 1.75 14.03 9.92 2.07 12.21 8.48 2.45 72 (22.2) 24.57 13.12 1.00 22.22 11.68 1.20 19.91 10.29 1.44 17.68 8.97 1.73 15.56 7.72 2.06 13.56 6.54 2.45
670
57 (13.9) 20.41 20.41 1.05 18.64 18.64 1.25 16.87 16.87 1.48 15.14 15.14 1.76 13.47 13.47 2.08 11.88 11.88 2.46 62 (16.7) 20.46 20.36 1.05 18.67 18.67 1.25 16.90 16.90 1.48 15.16 15.16 1.76 13.49 13.49 2.08 11.90 11.90 2.46
63 (17.2)†† 20.64 15.91 1.05 18.66 14.25 1.25 16.69 12.63 1.48 14.78 11.07 1.76 12.96 9.58 2.09 11.26 8.17 2.46
67 (19.4) 22.34 16.64 1.03 20.20 14.92 1.23 18.09 13.25 1.47 16.04 11.64 1.75 14.09 10.10 2.08 12.26 8.64 2.45 72 (22.2) 24.67 13.29 1.01 22.31 11.84 1.21 19.99 10.43 1.45 17.75 9.09 1.73 15.61 7.83 2.06 13.60 6.64 2.45
700
57 (13.9) 20.70 20.70 1.05 18.90 18.90 1.25 17.10 17.10 1.48 15.34 15.34 1.76 13.64 13.64 2.08 12.03 12.03 2.46 62 (16.7) 20.73 20.73 1.05 18.93 18.93 1.25 17.13 17.13 1.48 15.36 15.36 1.76 13.66 13.66 2.08 12.05 12.05 2.46
63 (17.2)†† 20.79 16.28 1.05 18.79 14.59 1.25 16.80 12.94 1.49 14.87 11.35 1.77 13.04 9.83 2.09 11.33 8.38 2.47
67 (19.4) 22.49 17.03 1.03 20.33 15.28 1.23 18.20 13.58 1.47 16.13 11.93 1.75 14.16 10.36 2.08 12.33 8.87 2.46 72 (22.2) 24.82 13.53 1.01 22.44 12.06 1.21 20.10 10.64 1.45 17.84 9.28 1.73 15.69 7.99 2.07 13.66 6.78 2.45
See notes on page 15
