11
DETAI LED COOLING CAPACITIES#
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Tota l Sens‡ To t al Sens‡ Tota l Sens‡ To t a l Sens‡ Tot a l Sens‡ To t al Sens‡
24ACB724A**31 Outdoor Section With CNPV*3117A**+58CV(A,X)090--- 16 Indoor Section --- High
600
57 (13.9) 24.35 24.35 1.59 21.95 21.95 1.68 19.59 19.59 1.78 17.29 17.29 1.90 15.06 15.06 2.03 12.92 12.92 2.18
62 (16.7) 25.97 21.39 1.60 23.22 19.39 1.69 20.53 17.42 1.79 17.94 15.51 1.90 15.45 13.65 2.03 13.09 11.86 2.18
63 (17.2)†† 26.50 17.74 1.60 23.69 16.00 1.69 20.94 14.30 1.79 18.29 12.65 1.91 15.74 11.06 2.03 13.32 9.54 2.18
67 (19.4) 28.68 18.42 1.61 25.64 16.63 1.71 22.68 14.88 1.80 19.82 13.18 1.92 17.07 11.54 2.04 14.47 9.98 2.19
72 (22.2) 31.66 15.36 1.63 28.31 13.79 1.72 25.04 12.27 1.82 21.89 10.80 1.93 18.87 9.39 2.06 16.01 8.05 2.21
650
57 (13.9) 25.14 25.14 1.60 22.64 22.64 1.69 20.19 20.19 1.80 17.81 17.81 1.91 15.50 15.50 2.04 13.29 13.29 2.18
62 (16.7) 26.46 22.38 1.61 23.65 20.29 1.70 20.90 18.25 1.80 18.25 16.26 1.91 15.71 14.32 2.04 13.33 13.26 2.19
63 (17.2)†† 26.98 18.42 1.61 24.11 16.62 1.70 21.29 14.87 1.80 18.57 13.16 1.92 15.98 11.52 2.04 13.51 9.95 2.19
67 (19.4) 29.19 19.14 1.63 26.08 17.29 1.72 23.05 15.48 1.81 20.12 13.72 1.93 17.32 12.03 2.05 14.66 10.41 2.20
72 (22.2) 32.19 15.83 1.64 28.75 14.22 1.73 25.41 12.65 1.83 22.20 11.14 1.94 19.12 9.70 2.07 16.20 8.32 2.21
700
57 (13.9) 25.85 25.85 1.61 23.27 23.27 1.71 20.74 20.74 1.81 18.28 18.28 1.92 15.90 15.90 2.05 13.62 13.62 2.19
62 (16.7) 26.90 23.34 1.62 24.03 21.18 1.71 21.23 19.06 1.81 18.53 16.98 1.92 15.97 15.81 2.05 13.65 13.65 2.20
63 (17.2)†† 27.40 19.08 1.62 24.46 17.23 1.71 21.59 15.42 1.81 18.83 13.66 1.92 16.18 11.97 2.05 13.67 10.34 2.20
67 (19.4) 29.63 19.84 1.64 26.45 17.93 1.73 23.35 16.07 1.82 20.38 14.26 1.93 17.52 12.51 2.06 14.82 10.84 2.21
72 (22.2) 32.64 16.28 1.65 29.13 14.63 1.74 25.73 13.02 1.84 22.46 11.48 1.95 19.33 10.00 2.08 16.37 8.58 2.22
750
57 (13.9) 26.50 26.50 1.63 23.85 23.85 1.72 21.24 21.24 1.82 18.71 18.71 1.93 16.26 16.26 2.06 13.93 13.93 2.20
62 (16.7) 27.30 24.28 1.63 24.37 22.04 1.72 21.53 19.84 1.82 18.80 17.68 1.93 16.29 16.29 2.06 13.95 13.95 2.20
63 (17.2)†† 27.76 19.72 1.63 24.77 17.82 1.72 21.86 15.96 1.82 19.04 14.15 1.93 16.35 12.41 2.06 13.82 10.73 2.20
67 (19.4) 30.00 20.53 1.65 26.77 18.56 1.73 23.63 16.64 1.83 20.59 14.78 1.94 17.70 12.98 2.07 14.96 11.25 2.21
72 (22.2) 33.03 16.71 1.66 29.46 15.02 1.75 26.01 13.38 1.85 22.68 11.80 1.96 19.51 10.29 2.08 16.51 8.84 2.23
800
57 (13.9) 27.10 27.10 1.64 24.38 24.38 1.73 21.70 21.70 1.83 19.10 19.10 1.94 16.60 16.60 2.07 14.20 14.20 2.21
62 (16.7) 27.65 25.20 1.64 24.69 22.88 1.73 21.82 20.59 1.83 19.13 19.13 1.94 16.62 16.62 2.07 14.22 14.22 2.21
63 (17.2)†† 28.08 20.35 1.64 25.05 18.40 1.73 22.09 16.49 1.83 19.23 14.63 1.94 16.51 12.83 2.07 13.94 11.11 2.21
67 (19.4) 30.34 21.20 1.66 27.05 19.18 1.74 23.86 17.21 1.84 20.78 15.29 1.95 17.85 13.44 2.08 15.08 11.66 2.22
72 (22.2) 33.37 17.13 1.67 29.75 15.40 1.76 26.25 13.73 1.85 22.88 12.12 1.96 19.67 10.57 2.09 16.63 9.09 2.24
835
57 (13.9) 27.50 27.50 1.65 24.72 24.72 1.74 22.00 22.00 1.83 19.36 19.36 1.95 16.81 16.81 2.07 14.38 14.38 2.22
62 (16.7) 27.89 25.83 1.65 24.90 23.45 1.74 22.03 22.03 1.83 19.39 19.39 1.95 16.84 16.84 2.07 14.40 14.40 2.22
63 (17.2)†† 28.29 20.79 1.65 25.22 18.80 1.74 22.23 16.85 1.84 19.35 14.96 1.95 16.61 13.13 2.07 14.02 11.38 2.22
67 (19.4) 30.54 21.66 1.66 27.22 19.61 1.75 24.00 17.60 1.85 20.90 15.65 1.96 17.95 13.76 2.08 15.16 11.94 2.23
72 (22.2) 33.58 17.41 1.68 29.93 15.67 1.76 26.39 13.97 1.86 23.00 12.33 1.97 19.77 10.77 2.10 16.70 9.27 2.24
900
57 (13.9) 28.17 28.17 1.66 25.31 25.31 1.75 22.51 22.51 1.85 19.79 19.79 1.96 17.18 17.18 2.08 14.67 14.67 2.23
62 (16.7) 28.32 26.95 1.66 25.34 25.34 1.75 22.55 22.55 1.85 19.82 19.82 1.96 17.20 17.20 2.08 14.70 14.70 2.23
63 (17.2)†† 28.63 21.58 1.66 25.50 19.52 1.75 22.47 17.51 1.85 19.55 15.56 1.96 16.77 13.67 2.08 14.15 11.85 2.23
67 (19.4) 30.88 22.51 1.68 27.51 20.38 1.76 24.24 18.31 1.86 21.10 16.29 1.97 18.11 14.34 2.09 15.28 12.46 2.24
72 (22.2) 33.93 17.93 1.69 30.22 16.14 1.78 26.64 14.41 1.87 23.20 12.73 1.98 19.92 11.12 2.11 16.82 9.58 2.25
See notes on page 15
24ACB7
