CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ACB736A**31 --- Low
30
( --- 1.11)
TCG 20.70 20.10 19.50 18.80 18.00 16.90 15.60 14.10
SDT 65.70 75.40 85.10 94.80 104.50 114.10 123.60 133.10
KW 1.18 1.31 1.47 1.66 1.88 2.13 2.43 2.78
35
(1.67)
TCG 23.10 22.40 21.80 21.00 20.10 19.00 17.60 16.00
SDT 66.80 76.50 86.10 95.80 105.40 115.00 124.50 134.00
KW 1.16 1.30 1.46 1.65 1.87 2.12 2.42 2.76
40
(4.44)
TCG 25.60 25.00 24.20 23.40 22.40 21.20 19.80 18.10
SDT 68.00 77.60 87.30 96.90 106.50 116.00 125.40 134.90
KW 1.13 1.28 1.45 1.64 1.86 2.11 2.41 2.75
45
(7.22)
TCG 28.40 27.70 26.90 26.00 24.90 23.70 22.10 20.30
SDT 69.30 78.80 88.40 98.00 107.50 117.00 126.40 135.80
KW 1.11 1.26 1.43 1.63 1.85 2.10 2.40 2.73
50
(10.0)
TCG 31.40 30.60 29.70 28.70 27.60 26.20 24.60 22.70
SDT 70.60 80.10 89.60 99.20 108.60 118.00 127.40 136.70
KW 1.08 1.24 1.42 1.61 1.84 2.09 2.39 2.72
55
(12.78)
TCG 34.60 33.70 32.70 31.70 30.40 29.00 27.30 25.30
SDT 72.00 81.50 90.90 100.40 109.80 119.10 128.40 137.60
KW 1.06 1.22 1.40 1.60 1.83 2.08 2.38 2.71
60
(15.56)
TCG 38.10 37.00 36.00 34.80 33.50 31.90 30.10 28.00
SDT 73.50 82.90 92.30 101.60 111.00 120.20 129.40 138.60
KW 1.03 1.20 1.38 1.59 1.82 2.07 2.36 2.69
24ACB748A**31 --- High
30
( --- 1.11)
TCG 44.30 42.30 39.70 36.70 33.50 30.30 27.10 24.20
SDT 69.60 79.40 88.90 98.30 107.70 117.10 126.50 136.00
KW 2.00 2.27 2.56 2.88 3.24 3.67 4.16 4.76
35
(1.67)
TCG 49.40 47.10 44.10 40.80 37.30 33.80 30.40 27.20
SDT 71.20 80.80 90.30 99.60 108.90 118.20 127.60 137.00
KW 2.04 2.31 2.60 2.91 3.28 3.70 4.21 4.80
40
(4.44)
TCG 54.80 52.00 48.70 45.10 41.30 37.50 33.90 30.40
SDT 72.80 82.30 91.60 100.90 110.20 119.40 128.70 138.00
KW 2.08 2.35 2.63 2.95 3.32 3.75 4.25 4.86
45
(7.22)
TCG 60.40 57.20 53.50 49.60 45.50 41.40 37.50 33.80
SDT 74.40 83.80 93.00 102.20 111.40 120.60 129.80 139.10
KW 2.12 2.38 2.67 2.99 3.36 3.79 4.31 4.91
50
(10.0)
TCG 66.10 62.60 58.60 54.30 49.90 45.50 41.40 37.40
SDT 76.00 85.30 94.50 103.60 112.70 121.80 131.00 140.20
KW 2.15 2.41 2.70 3.02 3.40 3.84 4.36 4.98
55
(12.78)
TCG 72.10 68.10 63.80 59.10 54.40 49.80 45.30 41.10
SDT 77.60 86.80 95.90 105.00 114.00 123.10 132.10 141.30
KW 2.18 2.44 2.73 3.06 3.44 3.89 4.42 5.04
60
(15.56)
TCG 78.20 73.80 69.10 64.10 59.10 54.20 49.50 44.90
SDT 79.30 88.40 97.40 106.40 115.40 124.30 133.30 142.30
KW 2.20 2.46 2.76 3.09 3.48 3.94 4.48 5.11
24ACB748A**31 --- Low
30
( --- 1.11)
TCG 27.10 26.70 25.90 24.60 23.00 21.00 18.70 16.20
SDT 65.00 74.70 84.40 93.90 103.40 112.80 122.20 131.50
KW 1.44 1.66 1.90 2.18 2.49 2.84 3.25 3.71
35
(1.67)
TCG 30.20 29.70 28.80 27.50 25.90 23.80 21.50 18.80
SDT 66.00 75.70 85.30 94.80 104.30 113.70 123.10 132.40
KW 1.41 1.64 1.88 2.16 2.47 2.83 3.23 3.69
40
(4.44)
TCG 33.50 33.00 32.10 30.70 29.00 26.90 24.40 21.70
SDT 67.10 76.80 86.30 95.80 105.30 114.60 124.00 133.30
KW 1.38 1.61 1.86 2.14 2.45 2.81 3.22 3.68
45
(7.22)
TCG 37.00 36.50 35.60 34.20 32.40 30.20 27.70 24.80
SDT 68.30 77.90 87.40 96.90 106.30 115.60 124.90 134.10
KW 1.35 1.58 1.84 2.12 2.44 2.79 3.20 3.66
50
(10.0)
TCG 40.90 40.30 39.40 37.90 36.10 33.80 31.20 28.20
SDT 69.50 79.10 88.60 98.00 107.40 116.60 125.80 135.00
KW 1.32 1.56 1.81 2.10 2.42 2.78 3.18 3.64
55
(12.78)
TCG 45.00 44.50 43.50 42.00 40.10 37.80 35.00 31.90
SDT 70.90 80.40 89.80 99.20 108.50 117.70 126.90 136.00
KW 1.29 1.53 1.79 2.08 2.40 2.76 3.16 3.62
60
(15.56)
TCG 49.60 49.00 47.90 46.40 44.40 42.00 39.20 35.90
SDT 72.30 81.80 91.10 100.40 109.70 118.80 127.90 137.00
KW 1.26 1.50 1.77 2.06 2.38 2.74 3.15 3.60
