CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ACB760A**30 HIGH
30
(---1.11)
TCG 52.30 49.80 47.20 44.50 41.60 38.60 35.40 32.00
SDT 70.40 79.70 89.00 98.30 107.60 116.80 126.00 135.20
KW 2.27 2.61 2.97 3.34 3.74 4.18 4.67 5.21
35
(1.67)
TCG 58.00 55.20 52.40 49.40 46.20 42.90 39.50 35.80
SDT 72.00 81.20 90.40 99.60 108.80 117.90 127.00 136.10
KW 2.33 2.67 3.02 3.40 3.80 4.24 4.73 5.27
40
(4.44)
TCG 64.10 61.10 57.90 54.70 51.20 47.70 43.90 39.90
SDT 73.70 82.70 91.80 101.00 110.10 119.10 128.20 137.20
KW 2.40 2.73 3.09 3.46 3.87 4.31 4.81 5.35
45
(7.22)
TCG 70.60 67.40 63.90 60.30 56.60 52.70 48.60 44.20
SDT 75.40 84.20 93.30 102.20 111.50 120.50 129.40 138.20
KW 2.47 2.80 3.15 3.52 3.94 4.39 4.88 5.42
50
(10.0)
TCG 77.70 74.10 70.30 66.40 62.30 58.10 53.60 48.80
SDT 77.30 85.90 94.90 103.90 112.90 121.90 130.70 139.40
KW 2.55 2.87 3.22 3.60 4.01 4.47 4.96 5.51
55
(12.78)
TCG 85.30 81.30 77.20 72.90 68.40 63.70 58.90 53.70
SDT 79.30 88.10 96.90 105.70 114.50 123.20 132.00 140.70
KW 2.64 2.96 3.31 3.69 4.10 4.55 5.05 5.60
60
(15.56)
TCG 93.30 89.00 84.40 79.70 74.90 69.70 64.40 58.70
SDT 81.40 90.10 98.80 107.40 116.10 124.80 133.40 141.90
KW 2.74 3.06 3.40 3.78 4.19 4.64 5.14 5.70
24ACB760A**30 LOW
30
(---1.11)
TCG 34.80 33.30 31.50 29.60 27.50 25.30 23.00 20.60
SDT 64.40 74.00 83.60 93.10 102.70 112.20 121.60 131.10
KW 1.65 1.96 2.27 2.60 2.98 3.41 3.90 4.49
35
(1.67)
TCG 39.00 37.30 35.30 33.20 30.90 28.50 25.90 23.30
SDT 65.50 75.00 84.50 94.00 103.50 112.90 122.40 131.80
KW 1.64 1.94 2.25 2.57 2.94 3.36 3.85 4.42
40
(4.44)
TCG 43.60 41.60 39.40 37.10 34.60 31.90 29.20 26.30
SDT 66.70 76.10 85.60 95.00 104.40 113.80 123.20 132.50
KW 1.64 1.93 2.23 2.55 2.90 3.31 3.79 4.35
45
(7.22)
TCG 48.50 46.30 43.90 41.30 38.50 35.60 32.60 29.40
SDT 68.00 77.30 86.70 96.10 105.40 114.70 124.00 133.20
KW 1.64 1.92 2.21 2.52 2.87 3.27 3.74 4.28
50
(10.0)
TCG 53.80 51.30 48.70 45.80 42.80 39.60 36.30 32.80
SDT 69.30 78.60 87.90 97.20 106.40 115.60 124.80 134.00
KW 1.64 1.91 2.20 2.50 2.84 3.23 3.68 4.22
55
(12.78)
TCG 59.50 56.70 53.80 50.70 47.40 43.90 40.20 36.30
SDT 70.80 80.00 89.20 98.30 107.50 116.60 125.80 134.80
KW 1.65 1.91 2.19 2.48 2.81 3.19 3.64 4.16
60
(15.56)
TCG 65.60 62.50 59.30 55.90 52.20 48.40 44.30 40.00
SDT 72.30 81.40 90.50 99.60 108.60 117.70 126.70 135.70
KW 1.66 1.92 2.18 2.47 2.79 3.16 3.59 4.10
* AHRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling Capacity (1000 Btuh)
