ITEM INFORMATION TEMPERATURES PRESSURES SETPOINTS INPUTS OUTPUTS CONFIGURATIONS ALARMS ALARMS HIST. OPERATING LOG
0 Operating Evaporator Circuit A Cooling Remote Compressor Password Number of Historic Unit
type water entering discharge setpoint 1 start/stop status active alarms/ alarm code 1** operating
temperature pressure contact status resets hours/10
1 Mode Evaporator Circuit A Cooling Remote Loader Master circuit Active alarm Historic Circuit A
water leaving suction setpoint 2 stepoint contact status select* code 1** alarm code 2** operating
temperature pressure status hours/10
2 Mode* Copndenser Oil pressure Heating Remote Motor cooling Circuit Active Historic Compressor A1
water entering A1* setpoint* heat/cool valve status loading alarm code 2** alarm code 3** operating
temperature* contact status* circuit A sequence* hours/10*
3 Mode* Condenser Oil pressure Condensing Remote Motor cooling Delay at Active Historic Compressor A2
water leaving A2 setpoint* reclaim operat. valve status start-up alarm code 3** alarm code 4** operating
temperature* contact status* circuit B in minutes hours/10*
4 Mode* Reclaim Oil differential Reclaim Capacity Oil solenoid Ramp Active Hisotric Compressor B
water entering pressure setpoint* reduction status loading alarm code 4** alarm code 5** operating
temperature* compressor A1* contact status* selection hours/10*
5 Mode* Reclaim Oil differential Capacity Evaporator Oil heater Setpoint Active Historic Compressor B1
water leaving pressure reduction water flow status reset alarm code 5** alarm code 6** operating
temperature* compressor A2* setpoint as % control contact selection hours/10*
6 Cooling/heating* Saturated Economizer Cooling Condenser Oil pimp Demand - Historic Compressor B2
discharge temp. pressure loading water flow status limit alarm code 7** operating
circuit A A1* rate ramp control contact selection hours/10*
7 Number of Saturated Economizer Heating Oil level Fan status Software - Historic Number of
capacity suction temp. pressure loading circuit A A1 - A2 - version alarm code 8** units
stages circuit A A2* rate ramp* A3- A4 number start-ups/10*
8 Present Discharge gas Discharge Cooling - 0-10 V Oil level Fan status ENO - Historic Number of
demand temperature pressure d.c. signal for circuit B B1 - B2 - alarm code 9** compressor A1
limit in % circuit A circuit B* zero reset* B3 - B4* start-ups/10*
9 Unit Discharge Suction Cooling - 0-10 V Water flow contr. Alarm circuit A BUS - Historic Number of
capacity superheat, pressure d.c. signal for contact heat and alarm circuit alarm code 10** compressor A2
in % circuit A circuit B* full reset* reclaim condenser B status start-ups/10*
10 Capacity Motor Oil pressure Cooling - delta Drain pressostat Position - - - Number of
circuit A temperature A1 B1* temperature for contact EXV A in %* compressor A2
circuit A star-ups/10
11 Capacity Motor Oil pressure Cooling - delta Drain pressostat Position - - - Number of
circuit B temperature A2 B2* temperature for contact EXV B in %* compressor B1
in %* full reset* circuit B start-ups/10*
12 Active Saturated disch. Oil differential Cooling - Evaporator Fan speed/ - - - Number of
setpoint temperature pressure full reset fluid level valve position compressor B2
compressor B compressor B1 degrees value* circuit A circuit A in %* start-ups/10*
13 Control Saturated suction Oil differential Heating - 0-10 V Evaporator Fan speed - - - Max. number of
point temperature pressure d.c. signal for fluid level circuit B start-ups
Ciucuit B compressor B2 zero reset* circuit B in %* last hour
14 Active Discharge temp. Economizer Heating - 0-10 V 0-10 V Evaporator and - - - Max. number of
condensing circuit B* pressure d.c. signal for external signal condenser pump average start-ups
setpoint* B1* full reset* status last 24 hours
15 Capacity Discharge Economizer Heating - delta - Evaporator and - - - -
override superheat, pressure temperature for reclaim cond.
circuit B B2* zero reset* heater status
16 EXV Motor - Heating - delta - Reclaim cond. - - - -
override temperature B1 temperature for water valve
zero reset* position in %
17 hr_status Motor - Heating - full - Heat reclaim - - - -
heat reclaim temperature B2 reset degrees solenoid valve
mode value* status
18 SMZ Outdoor - - - Local test - - - -
temperature interface
19 ZM - - - - - - - - -
Key:
* Displayed if the configuration requires it.
** Displayed if the alarm exists.
- Not in use.
