Carrier 38QRF018 - Troubleshooting

14
TROUBLESHOOTING
LEGEND
NOTE: For systems with indoor units equipped with microprocessor
control, see separate controls, service, and troubleshooting manual.
NC — Normally Closed
ODT — Outdoor Thermostat
A07435
Fig. 11 -- Troubleshooting the Cooling Cycle
