5.3 A6 Ducted
Model
unit
A
B
C
D
E
F
G
H
I
J
K
L
M
H1
H2
W1
W2
(KBtu/h)
7/9/12
mm
700
200
506
450
137
537
30
152
599
186
50
741
360
84
140
84
84
inch
27.56
7.87
19.92
17.72
5.39
21.14
1.18
5.98
23.58
7.32
1.97
29.17
14.17
3.31
5.51
3.31
3.31
18
mm
880
210
674
600
140
706
50
136
782
190
40
920
508
78
148
88
112
inch
34.65
8.27
26.54
23.62
5.51
27.8
1.97
5.35
30.79
7.48
1.57
36.22
20
3.07
5.83
3.46
4.41
24
mm
1100
249
774
700
140
926
50
175
1001
228
5
1140
598
80
150
130
155
inch
43.31
9.80
30.47
27.56
5.51
36.46
1.97
6.89
39.41
8.98
0.2
44.88
23.54
3.15
5.91
5.12
6.10
