Detailed cooling capacities* (S.I.)
See notes on pg. 8.
COIL
AIR
CONDENSER ENTERING AIR TEMPERATURES °C
28 32 36 40 44 48 52
L/S
(C)
EWB
Capacity
Kw†
Sys.
Power
Kw**
Capacity
Kw†
Sys.
Power
Kw**
Capacity
Kw†
Sys.
Power
Kw**
Capacity
Kw†
Sys.
Power
Kw**
Capacity
Kw†
Sys.
Power
Kw**
Capacity
Kw†
Sys.
Power
Kw**
Capacity
Kw†
Sys.
Power
Kw**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
Total
Sens‡
38YCB024-70 Outdoor Section With F(A,B)4ASF024 Indoor Section
340
22 7.83 3.94 2.56 7.50 3.81 2.68 7.17 3.69 2.80 6.84 3.57 2.91 6.50 3.44 3.02 6.16 3.32 3.13 5.81 3.20 3.23
20 7.32 4.64 2.49 7.01 4.51 2.61 6.70 4.39 2.72 6.38 4.26 2.83 6.06 4.14 2.93 5.73 4.01 3.03 5.40 3.88 3.13
18 6.84 5.33 2.43 6.55 5.20 2.54 6.25 5.06 2.65 5.96 4.93 2.75 5.66 4.79 2.85 5.36 4.64 2.95 5.05 4.48 3.05
16 6.46 5.89 2.38 6.19 5.74 2.49 5.93 5.58 2.59 5.66 5.42 2.70 5.39 5.25 2.80 5.12 5.06 2.90 4.84 4.84 2.99
14 6.25 6.22 2.35 6.03 6.00 2.46 5.80 5.79 2.57 5.57 5.56 2.68 5.34 5.33 2.79 5.09 5.09 2.89 4.84 4.84 2.99
380
22 7.96 4.09 2.61 7.62 3.96 2.73 7.28 3.84 2.85 6.93 3.71 2.96 6.58 3.59 3.07 6.23 3.47 3.18 5.88 3.35 3.28
20 7.45 4.86 2.54 7.12 4.74 2.66 6.80 4.61 2.77 6.47 4.48 2.88 6.14 4.35 2.99 5.80 4.23 3.09 5.47 4.10 3.18
18 6.97 5.62 2.48 6.67 5.48 2.59 6.36 5.34 2.70 6.06 5.20 2.81 5.76 5.04 2.91 5.46 4.86 3.01 5.17 4.67 3.11
16 6.61 6.20 2.43 6.34 6.03 2.54 6.06 5.87 2.65 5.79 5.69 2.76 5.52 5.49 2.86 5.26 5.26 2.96 5.00 5.00 3.07
14 6.47 6.45 2.41 6.23 6.22 2.53 6.00 5.99 2.64 5.76 5.75 2.75 5.51 5.51 2.86 5.26 5.26 2.96 5.00 5.00 3.07
420
22 8.06 4.23 2.66 7.72 4.11 2.78 7.37 3.98 2.89 7.01 3.86 3.01 6.65 3.73 3.12 6.29 3.61 3.23 5.93 3.49 3.33
20 7.55 5.08 2.59 7.22 4.95 2.70 6.88 4.82 2.82 6.54 4.70 2.93 6.21 4.57 3.03 5.87 4.44 3.13 5.52 4.31 3.23
18 7.08 5.89 2.53 6.77 5.75 2.64 6.46 5.60 2.75 6.16 5.43 2.86 5.86 5.24 2.96 5.56 5.05 3.07 5.26 4.84 3.17
16 6.74 6.48 2.48 6.46 6.30 2.59 6.18 6.11 2.70 5.91 5.90 2.81 5.65 5.65 2.92 5.39 5.39 3.03 5.12 5.12 3.13
14 6.65 6.64 2.47 6.41 6.40 2.59 6.16 6.15 2.70 5.91 5.91 2.81 5.65 5.65 2.92 5.39 5.39 3.03 5.13 5.13 3.13
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
F(A,B)4ASF 024 1.00 1.00 FG3ASA 024 0.97 1.02
030 1.02 1.00 — — —
38YCB036-70, 90 Outdoor Section With F(A,B)4ASF036 Indoor Section
500
22 11.9 6.04 3.60 11.4 5.86 3.77 10.9 5.68 3.94 10.4 5.50 4.11 9.92 5.32 4.27 9.42 5.14 4.42 8.90 4.96 4.58
20 11.1 7.14 3.51 10.6 6.95 3.67 10.2 6.77 3.83 9.69 6.58 3.99 9.21 6.40 4.14 8.73 6.21 4.29 8.25 6.03 4.43
18 10.3 8.21 3.42 9.91 8.01 3.58 9.48 7.81 3.74 9.04 7.61 3.89 8.60 7.40 4.04 8.17 7.16 4.18 7.73 6.90 4.32
16 9.78 9.05 3.36 9.39 8.82 3.51 8.99 8.58 3.67 8.60 8.34 3.82 8.21 8.07 3.96 7.82 7.77 4.11 7.43 7.43 4.26
14 9.51 9.47 3.32 9.18 9.15 3.48 8.85 8.83 3.64 8.51 8.49 3.80 8.16 8.15 3.95 7.80 7.80 4.11 7.43 7.43 4.26
5.60
22 12.1 6.29 3.68 11.6 6.11 3.85 11.1 5.93 4.02 10.6 5.75 4.18 10.1 5.56 4.35 9.53 5.38 4.50 8.99 5.20 4.65
20 11.3 7.51 3.58 10.8 7.32 3.75 10.3 7.13 3.91 9.83 6.94 4.07 9.33 6.75 4.22 8.84 6.56 4.37 8.34 6.37 4.51
18 10.5 8.67 3.49 10.1 8.47 3.65 9.65 8.25 3.81 9.21 8.03 3.97 8.77 7.77 4.12 8.33 7.49 4.27 7.90 7.20 4.42
16 10.0 9.53 3.43 9.61 9.28 3.59 9.21 9.02 3.75 8.81 8.74 3.90 8.43 8.40 4.06 8.04 8.04 4.21 7.66 7.66 4.36
14 9.84 9.82 3.41 9.49 9.47 3.58 9.14 9.13 3.74 8.78 8.77 3.90 8.42 8.41 4.06 8.04 8.04 4.21 7.66 7.66 4.36
640
22 12.3 6.61 3.77 11.8 6.43 3.94 11.3 6.24 4.11 10.7 6.06 4.28 10.2 5.87 4.44 9.65 5.69 4.60 9.10 5.50 4.75
20 11.5 7.98 3.67 11.0 7.78 3.84 10.5 7.59 4.00 9.98 7.40 4.16 9.47 7.20 4.32 8.96 7.01 4.47 8.45 6.81 4.61
18 10.8 9.24 3.59 10.3 9.00 3.75 9.85 8.75 3.91 9.41 8.46 4.07 8.98 8.16 4.23 8.53 7.86 4.38 8.08 7.56 4.53
16 10.3 10.1 3.53 9.87 9.79 3.69 9.47 9.47 3.86 9.09 9.09 4.02 8.70 8.70 4.18 8.31 8.31 4.34 7.91 7.91 4.49
14 10.2 10.2 3.52 9.84 9.84 3.69 9.47 9.47 3.86 9.09 9.09 4.02 8.70 8.70 4.18 8.31 8.31 4.34 7.92 7.92 4.49
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
F(A,B)4ASF 036 1.00 1.00 FG3ASA 036 0.98 1.00
F(A,B)4AS(F,B) 042 1.02 0.99 — — —
