9
Detailed cooling capacities* (English)
See notes on pg. 10.
COIL
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM
(F)
EWB
Capacity
MBtuh†
Sys.
Power
Kw**
Capacity
MBtuh†
Sys.
Power
Kw**
Capacity
MBtuh†
Sys.
Power
Kw**
Capacity
MBtuh†
Sys.
Power
Kw**
Capacity
MBtuh†
Sys.
Power
Kw**
Capacity
MBtuh†
Sys.
Power
Kw**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YCB024-70 Outdoor Section With F(A,B)4ASF024 Indoor Section
700
72 27.9 13.5 2.43 26.4 12.9 2.60 24.8 12.3 2.76 23.3 11.7 2.92 21.7 11.2 3.08 20.0 10.6 3.22
67 25.4 16.7 2.35 24.0 16.1 2.51 22.6 15.5 2.66 21.1 14.9 2.81 19.6 14.3 2.95 18.1 13.7 3.08
62 23.1 19.9 2.27 21.8 19.3 2.42 20.5 18.7 2.56 19.2 18.0 2.70 17.8 17.3 2.84 16.5 16.5 2.97
57 21.9 21.9 2.22 20.8 20.8 2.38 19.8 19.8 2.53 18.7 18.7 2.68 17.6 17.6 2.83 16.5 16.5 2.97
800
72 28.5 14.1 2.49 26.9 13.5 2.66 25.3 12.9 2.83 23.6 12.3 2.98 22.0 11.7 3.14 20.3 11.1 3.28
67 26.0 17.7 2.40 24.5 17.1 2.56 23.0 16.5 2.72 21.5 15.9 2.87 19.9 15.3 3.01 18.3 14.7 3.15
62 23.7 21.3 2.32 22.3 20.6 2.48 21.0 19.9 2.63 19.6 19.2 2.77 18.3 18.3 2.91 17.1 17.1 3.05
57 22.8 22.8 2.29 21.7 21.7 2.45 20.6 20.6 2.61 19.5 19.5 2.76 18.3 18.3 2.91 17.1 17.1 3.06
900
72 29.0 14.6 2.54 27.3 14.0 2.71 25.7 13.4 2.88 23.9 12.8 3.04 22.2 12.3 3.19 20.5 11.7 3.34
67 26.4 18.7 2.46 24.9 18.1 2.62 23.4 17.5 2.77 21.8 16.8 2.93 20.2 16.2 3.07 18.6 15.6 3.20
62 24.2 22.6 2.38 22.8 21.9 2.53 21.4 21.1 2.68 20.1 20.1 2.83 18.9 18.9 2.99 17.6 17.6 3.13
57 23.6 23.6 2.36 22.5 22.5 2.52 21.3 21.3 2.68 20.1 20.1 2.83 18.9 18.9 2.99 17.6 17.6 3.13
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
F(A,B)4ASF 024 1.00 1.00 FG3ASA 024 0.97 1.02
030 1.02 1.00 — — —
38YCB036-70, 90 Outdoor Section With F(A,B)4ASF036 Indoor Section
1050
72 42.5 20.8 3.43 40.2 19.9 3.67 37.9 19.1 3.91 35.6 18.2 4.14 33.2 17.4 4.36 30.7 16.5 4.57
67 38.6 25.9 3.31 36.5 25.1 3.54 34.3 24.2 3.76 32.1 23.3 3.98 29.9 22.4 4.18 27.6 21.5 4.38
62 35.0 31.0 3.20 33.1 30.0 3.42 31.2 29.1 3.63 29.2 28.1 3.83 27.3 27.0 4.04 25.4 25.4 4.24
57 33.5 33.5 3.15 31.9 31.9 3.37 30.4 30.4 3.60 28.8 28.8 3.81 27.1 27.1 4.03 25.4 25.4 4.24
1200
72 43.4 21.7 3.52 41.1 20.9 3.76 38.6 20.0 4.00 36.2 19.1 4.23 33.7 18.3 4.45 31.1 17.4 4.67
67 39.4 27.6 3.39 37.2 26.7 3.62 35.0 25.8 3.85 32.6 24.9 4.07 30.3 23.9 4.27 28.0 23.0 4.47
62 35.9 33.1 3.28 33.9 32.1 3.51 31.9 31.0 3.72 30.0 29.8 3.93 28.1 28.1 4.15 26.3 26.3 4.36
57 34.9 34.9 3.25 33.2 33.2 3.48 31.6 31.6 3.71 29.9 29.9 3.93 28.1 28.1 4.15 26.3 26.3 4.36
1350
72 44.1 22.6 3.60 41.7 21.8 3.84 39.2 20.9 4.08 36.7 20.0 4.31 34.0 19.2 4.54 31.4 18.3 4.75
67 40.1 29.1 3.47 37.8 28.2 3.70 35.4 27.3 3.93 33.1 26.4 4.15 30.7 25.4 4.36 28.4 24.5 4.56
62 36.6 35.1 3.37 34.6 33.9 3.59 32.6 32.6 3.81 30.8 30.8 4.04 29.0 29.0 4.26 27.1 27.1 4.48
57 36.0 36.0 3.35 34.3 34.3 3.58 32.6 32.6 3.81 30.8 30.8 4.04 29.0 29.0 4.26 27.1 27.1 4.48
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
F(A,B)4ASF 036 1.00 1.00 FG3ASA 036 0.98 1.00
F(A,B)4AS(F,B) 042 1.02 0.99 — — —
