7. Physical Data
Outdoor Unit Model 38QDMT12-718
Indoor Unit Model 42QDMT12-718
Power supply Ph-V-Hz 1Ph, 220-240V～, 50Hz
Cooling
Capacity
Btu/h 13000
Kw 3.81
Input W 1265
Rated current A 5.9
EER
Btu/wh 10.28
W/W 3.01
Heating
Capacity
Btu/h 12700
Kw 3.72
Input W 1045
Rated current A 5.1
COP W/W 3.56
Compressor
Model PH210M2A-4FTS1
Type Rotary Tropical
Brand GMCC / Toshiba
Capacity ( @ 220/240V ) ± 5% Btu/h 12760 / 12860
Input ( @ 220/240V ) ± 5% W 1181 / 1280
Rated current ( @ 220/240V ) ± 5% A 5.62 / 6.16
Locked rotor Amp( + 10% ) A 33.6
Thermal protector position Internal
Capacitor uF / V 35 uF / 370 V
Refrigerant oil SUNISO 4G5D or NM56EP or Eqv
oil charge ml 440
Outdoor fan motor
Model YDK24-6-12
Brand Welling
Input W 1/10
Capacitor uF / V 2.5 uF / 450 V
Speed r/min 865
Outdoor coil
a.Number of rows 1
b.Tube pitch(a)× row pitch(b) mm 21 x 13.37
c.Fin spacing mm 1.6
d.Fin type (code) Uncoated Aluminum
e.Tube outside dia.and type mm Ø 7, inner groove tube
f.Coil length × height × width mm 750 x 518 x 13.37
g.Number of circuits 2
Restrictor Size Cool / Heat C 0.041 / H 0.035
Outdoor air flow cfm (m
3
/h) 1062 ( 1800 )
Outdoor noise level dB(A) 56
Outdoor unit
Dimension (W*H*D) mm 780 x 540 x 250
Packing (W*H*D) mm 875 x 560 x 310
Net/Gross weight Kg 34 / 37
Indoor fan motor
Model YSK24-4C
Brand Welling
Input W 62 / 42 / 36
Capacitor uF 2 uF / 450 V
Speed(Hi/Mi/Lo) r/min 1180 / 830 / 730
Indoor coil
a.Number of rows 3
b.Tube pitch(a)× row pitch(b) mm 21 x 13.37
c.Fin spacing mm 1.5
d.Fin type (code) Precoated Hydrophilic Aluminum
e.Tube outside dia.and type mm Ø 7, inner groove tube
f.Coil length × height × width mm 515 x 252 x 40.11
g.Number of circuits 4
Indoor actual wet air flow (Hi/Mi/Lo) @ 0 external static pressure
cfm 400 / 345 / 250
m
3
/hr 678 / 585 / 424
Indoor maximum external static pressure Pa 40
Indoor noise level (Hi/Mi/Lo) dB(A) 38.1 / 33.5 / 25.6
Indoor unit
Dimension (W*H*D) (body) mm 700 x 210 x 635
Packing (W*H*D) (body) mm 915 x 290 x 655
Net/Gross weight (body) kg 20 / 25
Refrigerant type / quantity g R22 / 760
Design pressure MPa 2.94 / 1.0
Refrigerant piping
Liquid side/ Gas side mm(inch) Ø 6.35 / Ø 12.7 ( 1/4" / 1/2" )
Max. refrigerant pipe length m 10
Max. difference in level m 4
Drainage water pipe outside diameter mm ODØ 25
Control type Wired Control / Wireless Remote Control
Operation temperature
Ԩ
17 ~ 30
Ambient temperature (cooling/heating)
Ԩ
21 ~ 52 / 2 ~ 24
