108
APPENDIX C — CCN Points List (cont)
LEGEND *Sizes 088 and 104 only.
†Sizes 034-078 only.
CCN
TABLE NAME
CCN
POINT NAME
EXPANDED NAME
READ/WRITE
PROPERTIES
DISPLAY FORMAT/
ENGINEERING UNITS
STATUS04
(cont)
HHOVR High Humidity Override RO no/yes
IAQCL IAQ/Outdoor Air CFM Ctrl† RO no/yes
STATUS05
CPSA1 Compressor A1 Status RO on/off
CPFA1 Compressor A1 Safety RO alarm/norm
CMPA1 Compressor A1 RO on/off
CPFA2 Compressor A2 Safety† RO alarm/norm
CMPA2 Compressor A2† RO on/off
ULDA1 Unloader A1 RO on/off
ULDA2 Unloader A2† RO on/off
SDRA Cir A Solenoid* RO on/off
LPA Cir A Low Pressure RO alarm/norm
SPA Cir A Suction Pressure RO psi
DPA Cir A Discharge Pressure RO psi
SCTA Cir A Saturated Condensing Temperature RO F
SSTA Cir A Saturated Suction Temperature RO F
SHA Cir A Suction Superheat RO F
STA Cir A Suction Temperature RO F
MMA Cir A Motormaster/Fan 1 RO on/off
OFA Cir A Outdoor Fan 2 RO on/off
STATUS06
CPSB1 Compressor B1 Status RO on/off
CPFB1 Compressor B1 Safety RO alarm/norm
CMPB1 Compressor B1 RO on/off
CPFB2 Compressor B2 Safety† RO alarm/norm
CMPB2 Compressor B2† RO on/off
ULDB1 Unloader B1 RO on/off
ULDB2 Unloader B2† RO on/off
SDRB Cir B Solenoid* RO on/off
LPB Cir B Low Pressure RO alarm/norm
SPB Cir B Suction Pressure RO psi
DPB Cir B Discharge Pressure RO psi
SCTB Cir B Saturated Condensing Temperature RO F
SSTB Cir B Saturated Suction Temperature RO F
SHB Cir B Suction Superheat RO F
STB Cir B Suction Temperature RO F
MMB Cir B Motormaster/Fan 1 RO on/off
OFB Cir B Outdoor Fan 2 RO on/off
SETPOINT
OHSP Occupied Heat Set Point RW 55 to 80 F
OCSP Occupied Cool Set Point RW 55 to 80 F
UHSP Unoccupied Heat Set Point RW 40 to 80 F
UCSP Unoccupied Cool Set Point RW 75 to 95 F
HUSP Humidity Set Point RW 0 to 100%
SPSP Static Pressure Set Point RW 0.0 to 5.0 in. wg
BPSP Building Pressure Set Point RW –0.5 to +0.5 in. wg
SASP Supply Air Temperature Set Point RW 40 to 70 F
NTLO NTFC Lockout Temperature RW 40 to 70 F
RTIO Reset Ratio RW 0 to 10 F
LIMT Reset Limit RW 0 to 20 F
LSP Demand Limit Set Point RW 0 to 100%
MDP Economizer Minimum Damper Position RW 0 to 100%
OACS Outside Air CFM Set Point RW 0 to 50,000 CFM
IAQS IAQ Set Point RW 0 to 5000 PPM
HHOR High Humidity Override RW 0 to 100%
ECSO Economizer Set Point Offset RW 0 to 10 F
USDB Unoccupied Set Point Deadband* RW 0 to 10 F
UHDB Unoccupied Heating Deadband† RW 0 to 10 F
UCDB Unoccupied Cooling Deadband† RW 0 to 10 F
LTMP Low Temperature Minimum Position RW 0 to 100%
HTMP High Temperature Minimum Position RW 0 to 100%
OCCDEFCS
OCCPCO1S Occupancy Schedule TS
DAV
— Digital Air Volume
IAQ
— Indoor-Air Quality
NTFC
— Nighttime Free Cooling
RO
— Read Only
RW
— Read/Write
TS
— Time Schedule object with read/write properties
