Carrier 48FP - Page 110

110
APPENDIX D — BACnet Points List (cont)
LEGEND
*Sizes 088 and 104 only.
CCN
TABLE
NAME
CCN
POINT
NAME
BACnet
OBJECT
NAME
EXPANDED NAME
BACnet
OBJECT
TYPE
BACnet
OBJECT
PROPERTIES
BACLink
DEFAULT
TEMPLATE
DISPLAY FORMAT/
ENGINEERING
UNITS
SETPOINT
OHSP OHSP Occupied Heat Set Point AV RW Y 55 to 80 F
OCSP OCSP Occupied Cool Set Point AV RW Y 55 to 80 F
UHSP UHSP Unoccupied Heat Set Point AV RW Y 40 to 80 F
UCSP UCSP Unoccupied Cool Set Point AV RW Y 75 to 95 F
HUSP HUSP Humidity Set Point AV RW 0 to 100%
SPSP SPSP Static Pressure Set Point AV RW Y 0.0 to 5.0 in. wg
BPSP BPSP Building Pressure Set Point AV RW –0.5 to +0.5 in. wg
SASP SASP Supply Air Temperature Set Point AV RW Y 40 to 70 F
MDP MDP Economizer Minimum Damper Position AV RW Y 0 to 100%
OACS OACS Outside Air CFM Set Point AV RW 0 to 50,000 CFM
IAQS IAQS IAQ Set Point AV RW 0 to 5000 PPM
HHOR HHOR High Humidity Override AV RW 0 to 100%
OCCDEFCS
OCCPCO1 OCCPC01S Occupancy Schedule TS RW Y
Al
— Analog Input object type defined by BACnet to
have only read only properties.
AO
— Analog Output object type defined by BACnet to
have read and write properties.
AV
— Analog Value object type defined by BACnet to
have read and/or write properties.
BI
— Binary Input object type defined by BACnet to
have read only properties.
BO
— Binary Output object type defined by BACnet to
have read only properties.
BV
— Binary Value object type defined by BACnet to
have read and/or write properties.
RO
— Read Only
RW
— Read/Write
TS
— Time Schedule object with read/write properties
Y
— Yes, this object comes configured in the BACLink
template.
