Table 69 — Factory/Field Configuration Procedure
LEGEND
*Alarm 86, illegal configuration, will result if value is not inputted
correctly.
†For size 038, enter “034” for SIZE.
For size 048, enter “044” for SIZE.
For unit size 078, enter “074” for SIZE.
For unit size 088, enter “084” for SIZE.
For unit size 104, enter “‘108” for SIZE.
NOTES:
1. Calibration of the pressure transducers is not required unless prob-
lems with the transducers occur or the standard PSIO is replaced. To
calibrate pressure transducers:
a. Disconnect from system.
b. Hang in the atmosphere.
c. Read pressure. Pressures before calibration must be in the
range of ±3 psig (atmosphere).
d. Press .
e. Reattach to system.
2. Upon completion of the factory/field configuration step, move to the
DTRS (Data Reset) subfunction. Press , and all revised
inputs will be loaded. This procedure takes approximately 40 sec-
onds. The display returns to the default rotating display.
KEYPAD ENTRY DISPLAY COMMENTS
LOG ON
LOGGEDON
Must enter password
FACT CFG
Factory configuration
TYPE VAV
Unit type — Enter correct value
TYPE X
CV = 0, VAV = 1
SIZE 34
Unit size — Enter correct value:
SIZE X
034,044,054,064,074,084,108†
ULOP 2
Number of Unloaders (034-078 Only) — Enter value:
ULOP X
2, 3, or 4 (034-078 Only)
HPSP 113
Head pressure set point; Default = 113 F
HEAT 0
Heat type — Enter correct value:
HEAT X
0=None, 1 = Hot Water/Steam, 2 = Elec, 3 = Gas
HTSG 2
Number of Heat Stages (034-078 Only); Default: 2 stages (0-5 avail)
TRNS 0
Transducers option — Enter value:
TRNS X
0 = No; 1 = Yes
*
SF2S 0
Two-Speed Supply-Air Fan (034-078 Only); Default = No (0 = No, 1 = Yes)
ECON YES
Economizer Option — Enter value:
ECON X
0 = None, 1,2 = Air, 3 = Two-Position
FANT 0 (034-078)
PWRX 0 (088,104)
Fan type — Enter correct value:
FANT X (034-078)
PWRX X (088,104)
0 = none, 1 = Exhaust, 2 = Mod Exhaust, 3 = Mod Return
HUEN 0
Humidifier control
HUEN X
0 = none, 1 = Analog, 2 = Discrete
DTRS
Data reset (0 = No, 1 = Yes)
See Note 2 below
Edits being inputted; takes approximately 40 seconds.
DPA CALB
DPA CALB
Calibrate discharge pressure sensor A
DPB CALB
DPB CALB
Calibrate discharge pressure sensor B
SPA CALB
SPA CALB
Calibrate suction pressure sensor A
SPB CALB
SPB CALB
Calibrate suction pressure sensor B
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
AOSS —
Adaptive Optimal Start/Stop
CV —
Constant Volume
DTCC —
Discrete Time Clock Control
Elec —
Electric
IAQ —
Indoor-Air Quality
Mod —
Modulating
NTFC —
Nighttime Free Cool
SPT —
Space Temperature
VAV —
Variable Air Volume
IMPORTANT:
The Data Reset function should be performed any
time one or more of the values is configured. See Note 2 above
for more details.
ENTER
ENTER
