APPENDIX C: Navigatort Display
MODE -- RUN STATUS (cont)
ITEM EXPANSION RANGE UNIT WRITE STA TUS POINT
VENT Ventilation Status Menu
VENT Ventilation Status see Appendix B VENTTEXT
EC.MP MinPositioninEffect xxx % YES MIN_POS
EC.AP Econo Actual Position xxx % DAMPPOS
C.SPD Commanded IDF Speed xxx % FANSPEED
OCC Currently Occupied Yes/No YES OCCUPIED
PRE.O In Pre --- Occupancy Purge? Ye s/No PREOCCON
FC.ON Free Cooling active Yes/No FREECOOL
DF.AQ Differential Air Quality xxxx PPM AQ_DIFF
OK.PG Ok to Preoccupancy Purge Yes/No OKPREOCC
I.OV Is IAQ Override Active? Yes/No YES IAQ_OVRD
IO.SS IAQ override SW state Yes/No YES IAQ_OVRS
DCV.O IAQ DCV Curve Offset 0 to 100 IAQ_OFFS
I.FAN Indoor Fan Status Menu
C.SPD Commanded IDF Speed 0 t o 100 % FANSPEED
F. O VR IDF Speed Override Flag On/Off FAN_OVRD
F. B A D IDF Operation Errors? Yes/No IDFBAD
F. R E D IDF Speed Reduction On Ye s/No FANRED10
GEN General Status Of Menu
FT.RM Filter hour remaining xxxx hours FILTLEFT
R.FLT Reset Filter Timer Yes/No RESETFLT
DST.A DST currently active Yes/No DST_ACTV
TCS Temp Compensate Start On Ye s/No TCS_ACT
OCC OCCUPANCY DATA
OCC Currently Occupied Yes/No YES OCCUPIED
MT.OC Mins until next occupied xxxxx min MINTILOC
OC.CL Active Occupancy control 0=24/7 OCC,
1=SCHEDULE,
2=BAS CTRL,
3=REMOC CTL,
4=TIME OVRD,
5=LINKAGE,
6=FORCED
OCC_CTRL
LN.OC Linkage Occupied Request 0=Unocc,
1=Occupied,
2=Disabled
LNK_OCC
OV.EX Timed Override Remaining 0 to 240 min YES OVR_EXT
RM.OC Remote Occupancy Switch On/Off YES REMOCC
BMS.O BMS Occupancy Request 0=UNOCC,
1=OCCUPIED,
2=DISABLED
YES BMS_OCC
LC.OC Local Sched Occ Request 0=Unocc,
1=Occupied
YES LOC_OCC
PER.N Active Schedule period 0to8 PER_NO
HL.TW Tomorrow Is A Holiday Yes/No HOL_TMRW
HL.TY Today Is A Holiday Yes/No HOLTODAY
NOC.D Next Occupied Day DDD NXTOCDAY
NOC.T Next Occupied Time hh:mm NXTOCTIM
NUC.D Next Unoccupied Day DDD NXTUNDAY
NUC.T Next Unoccupied Time hh:mm NXTUNTIM
PUC.D Previous Unccupied Day DDD PRVUNDAY
PUC.T Previous Unoccupied Time hh:mm PRVUNTIM
