SEE NOTES: 1,2,4,7,8,9
on the page following
these figures
A03208
Fig. 26 -- Upflow Application--Vent Elbow Up
SEE NOTES: 1,2,3,4,7,8,9
on the pages following
these figures
A03209
Fig. 27 -- Upflow Application--Vent Elbow Right
SEE NOTES: 1,2,4,7,8,9 on the page
following these figures
A03213
Fig. 28 -- Horizontal Left Application -- Vent Elbow Left
SEE NOTES: 1,2,4,5,6,7,8,9
on the page following these figures
A03207
Fig. 29 -- Downflow Application-- Vent Elbow Left then Up
SEE NOTES: 1,2,4,7,8,9 on the page
following these figures
A03214
Fig. 30 -- Horizontal Right Application --Vent Elbow Right
SEE NOTES: 1,2,4,5,7,8,9 on the page
following these figures
A03215
Fig. 31 -- Horizontal Left Application--Vent Elbow Up
See NOTES following images.
