3
NOTE: ALL DIMENSIONS IN INCH (MM) U.S. ECCN: Not Subject to Regulation (N.S.R.)
SD5507---4 ULN 80 REV. B
A190257
Fig. 1 -- Dimensional Drawing
Table1–Dimensions
FURNACE SIZE
A
CABINET
WIDTH
IN. (MM)
B
OUTLET
WIDTH
IN. (MM)
C
TOP FLUE
COLLAR ONLY
IN. (MM)
D
BOTTOM
INLET WIDTH
IN. (MM)
VENT
CONNEC-
TION
IN. (MM)
SIZE
SHIP
WT. LB.
(KG)
ACCESSOR Y
FILTER
MEDIA
CABINET
SIZE
IN. (MM)
58SU0A040E17-12 17--- 1/2 (445) 15---7/8 (403) 11--- 9/16 (294) 16 (406) 4 (102) 118 (54) 16 (406)
58SU0A060E17-16 17--- 1/2 (445) 15---7/8 (403) 11--- 9/16 (294) 16 (406) 4 (102) 126 (57) 16 (406)
58SU0A080E21-20 21 (533) 19---3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102) 140 (64) 20 (508)
58SU0A100E21-20 21 (533) 19--- 3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102) 150 (68) 20 (508)
