PERFORMANCE DATA (cont)
ACCESSORY ELECTRIC HEATERS
HEATER
PART NO.
kW @
240V
VOLTS/
PH
STAGES (kW
OPERATING)
INTERNAL
CIRCUIT
PROTECTION
FAN COIL SIZE
USED WITH
HEATING CAP.**
@ 230V
KFCEH0401N03 3 230/1 3 None 018–024 9,400
KFCEH0501N05 5 230/1 5 None 018–060 15,700
KFCEH0801N08 8 230/1 8 None 018–060 25,100
KFCEH0901N10 10 230/1 10 None 018–060 31,400
KFCEH3201F20 20 230/1 5, 20 Fuse} 030–060 62,800
KFCEH1601315 15 230/3 5, 15 None 036–060 47,100
KFCEH2001318 18 230/3 6, 12, 18 None 042–060 56,500
KFCEH3401F24 24 230/3* 8, 16, 24 Fuse 048, 060 78,300
KFCEH3501F30 30 230/3* 10, 20, 30 Fuse 048, 060 94,100
KFCEH2401C05 5 230/1 5 Circuit Breaker 018–060 15,700
KFCEH2501C08 8 230/1 8 Circuit Breaker 018–060 25,100
KFCEH2601C10 10 230/1 10 Circuit Breaker 018–060 31,400
KFCEH3301C20 20 230/1 5, 20 Circuit Breaker 030–060 62,800
KFCEH2901N09 9 230/1{ 3, 9 None 036–060 28,200
KFCEH3001F15 15 230/1 5, 15 Fuse} 024–060 47,100
KFCEH3101C15 15 230/1 5, 15 Circuit Breaker 024–060 47,100
* Field convertible to 1 phase.
{ Fieldconvertibleto3phase.
} Single point wiring kit required for these heaters in Canada.
** Blower motor heat not included.
ESTIMATED SOUND POWER LEVEL (dBA)
UNIT SIZE
FY, FA
CONDITIONS OCTAVE BAND CENTER FREQUENCY*
CFM
Ext Static
Pressure
63 125 250 500 1000 2000 4000
018 600 0.25 64.7 60.7 56.7 53.7 51.7 49.7 45.7
024 800 0.25 66.0 62.0 58.0 55.0 53.0 51.0 47.0
030 1000 0.25 67.0 63.0 59.0 56.0 54.0 52.0 48.0
036 1200 0.25 67.8 63.8 59.8 56.8 54.8 52.8 48.8
042 1400 0.25 68.4 64.4 60.4 57.4 55.4 53.4 49.4
048 1600 0.25 69.0 65.0 61.0 58.0 56.0 54.0 50.0
060 2000 0.25 70.0 66.0 62.0 59.0 57.0 55.0 51.0
* Est. sound power levels have been derived using th e metho d described in th e 1987 ASHRAE HVAC Systems & Applications Handbook, Chap. 52, p. 52.7.
ELECTRICAL DATA FOR UNITS WITH FACTOR Y--INSTALLED HEATERS
MODEL NO
MTR
HP
MTR
FLA
HEAT PACK
INSTALLED
SINGLE CIRCUIT DUAL CIRCUIT
HTR
AMPS
MCA
MAX
OVERCUR
PROTECT
HTR
AMPS
MCA
MAX
OVERCUR
PROTECT
HTR
AMPS
MCA
MAX
OVERCUR
PROTECT
L1/L2 L1/L2 L1/L2 L3/L4 L3/L4 L3/L4
FY4ANB060010 3/4 5.2 MKFCE H0901N10 36.2/40.0 51.8/56.5 50/60 --- --- --- --- --- ---
FY4ANB060015 3/4 5.2 MKFC EH1501F15 54.2/59.9 74.3/81.4 80/80 36.2/40.0 51.8/56.5 60/60 18.1/20.0 22.6/25.0 25/25
FY4ANF018005 1/6 1.8 MKFCEH0501N05 18.1/20.0 24.9/27.3 25/30 --- --- --- --- --- ---
FY4ANF018008 1/6 1.8 MKFCEH0801N08 28.9/32.0 38.4/42.3 40/45 --- --- --- --- --- ---
FY4ANF024005 1/4 1.8 MKFCEH0501N05 18.1/20.0 24.9/27.3 25/30 --- --- --- --- --- ---
FY4ANF024010 1/4 1.8 MKFCEH0901N10 36.2/40.0 47.5/52.3 50/60 --- --- --- --- --- ---
FY4ANF030008 1/4 1.5 MKFCEH0801N08 28.9/32.0 38.0/41.9 40/45 --- --- --- --- --- ---
FY4ANF030010 1/4 1.5 MKFCEH0901N10 36.2/40.0 47.1/51.9 50/60 --- --- --- --- --- ---
FY4ANF036010 1/3 2.4 MKFCEH0901N10 36.2/40.0 48.3/53.0 50/60 --- --- --- --- --- ---
FY4ANF036015 1/3 2.4 MKFCEH1501F15 54.2/59.9 70.8/77.9 80/80 36.2/40.0 48.3/53.0 50/60 18.1/20.0 22.6/25.0 25/25
FY4ANF042010 1/2 2.9 MKFCEH0901N10 36.2/40.0 48.9/53.6 50/60 --- --- --- --- --- ---
FY4ANF042015 1/2 2.9 MKFCEH1501F15 54.2/59.9 71.4/78.5 80/80 36.2/40.0 48.9/53.6 50/60 18.1/20.0 22.6/25.0 25/25
FY4ANF048010 3/4 4.3 MKFCEH0901N10 36.2/40.0 50.6/55.4 50/60 --- --- --- --- --- ---
FY4ANF048015 3/4 4.3 MKFCEH1501F15 54.2/59.9 73.1/80.3 80/80 36.2/40.0 50.6/55.4 60/60 18.1/20.0 22.6/25.0 25/25
NOTE: All u nits 208/230, single---pha se, 60 Hz
MCA --- Minimum Circuit Amps
FLA --- Fu l l L o a d Am p s
FY4A / FA4C
