Carrier FA4C series - Slope Coil Diagrams; Dimensions Table (Cont)

5
A05356
DIMENSIONS (CONT)
UNIT SIZE
FY, FA
COIL TYPE
F G
in mm in mm
018 Slope 18 --- 1/8 460 18--- 5/8 473
024, 030 Slope 23 --- 1/8 587 23--- 5/8 600
036 Slope 26--- 15/16 684 27--- 1/2 699 042 A 23--- 7/16 593 23--- 1/8 587 048 A 27--- 1/4 692 2 6 --- 1 5 / 1 6 684 060 A 32--- 15/16 837 32--- 5/8 829
FY4A / FA4C
