Physical data
* Per ARI Standard 610, 60°F water, 0.20 in. wc.
† Single pole, single throw.
MODEL HUMCCSBP2017-A-- HUMCCLBP2018-A-- HUMCCLFP1025-A-- HUMCCSFP1016-A-- HUMCCWTR2019-A--
ARI CAPACITY*
Gallons/Day @ 140°F (Lbs/hr)
17 (5.9) 18 (6.3) 25 (8.7) 16 (5.6) 19 (6.6)
Gallons/Day @ 120°F (Lbs/hr) 12.8 (4.4) 13.5 (4.7) 18.8 (6.5) 12.8 (4.4) 14.3 (5.0)
TYPE
Airflow
Bypass Fan Bypass
Waterflow Drain Through No drain
GENERAL
Evaporator Pad Replacement
88NH1011C101 88NH1014C101 2-05923 88NH0901D101
Material of Evap Pad Treated Expanded Aluminum Polyether Foam
Size (In) (H x W x D) of Evap
Pad
10-7/8 x 10-7/16 x
1-3/4
14 x 10-5/8 x 1-3/4 9-3/4 x 9-1/4 x 1-1/4 9 Dia x 8-7/8
Pad Access
Side (Right or Left) with
Snap Latch
Top and Bottom with Thumbscrew Side (Right or Left) and
Front Access
Front with 2 Pawl
Latches
Unit Size (H x W x D)
13-3/4 x 13-3/4 x
7-5/16
15-3/8 x 16-5/8 x
5-13/16
15-3/8 x 16-5/8 x
8-13/16
12.5 x 12 x 10.18 11-1/2 x 11-7/8 x
11-7/8
Weight (lb) 8.9 8.5 15 10.9 11.4
Water Usage (Gal/hr) 3.2 Float Controlled
ELECTRICAL CONTROL
Low-Voltage Terminals
Volts
24 vac
Amps (Max) 0.50 0.13
VA (Max) 12 3
Watts 10 3
High-Voltage Cord
Volts
NA 115v - 1Ph - 60Hz NA
Amps NA 1.00 1.9 NA
CONNECTIONS
Water Inlet
1/4-in. Tubing or 3/4-in. Garden Hose 1/4-in. Tubing
Water Drain 5/8-in.Tubing 1/2- or 5/8-in. Tubing 5/8-in. tube 1/2-in. Tubing
Duct
6-in. Round,
Right/Left
6-inch Round, Front NA 6-in. Round,
Right/Left
Duct Opening (In) (W x H) 11-1/2 x 11-3/4 15-1/2 x 13-1/2 15-1/2 x 13-1/2 11.50 x 11.00 11-7/8 x 11-1/2
MATERIALS
Cabinet
Silver Sage
Material
High Temperature, Thermoplastic (Lexan) Prepainted Galvanized
Steel
Valve Nylon Polypropylene
Water Pan NA Polypropylene
Drum NA Polypropylene
STANDARD EQUIPMENT
Water Valve
Solenoid, 24 vdc Solenoid, 24 vdc Converted to 24 vac Float
Rectifier, 24 VAC 24 vac, 24 vdc NA
Motor
NA Thermally
Protected
115 vac,1/60 Hp
Thermally
Protected
115 vac, 25MHP
24 vac,
Synchronous
Relay
NA SPST†, 24 vac
to ac
SPST, 24vdc
to ac
NA
Humidistat SPST
Saddle Valve Standard
Damper Standard N/A Standard
Template Standard
Mounting Hardware Standard
