Carrier Infinity 59TN6A - Air Delivery Performance Data; Cooling Airflow Delivery; Heating Airflow Delivery

6
AIR DELIVERY
COOLING
4
AND HEATING AIR DELIVERY - CFM (Bottom Return
5
With Filter)
(SW1-5 and SW4-3 set to OFF, except as indicated. See notes 1 and 2.)
Unit Size Clg/CF Switch Settings External Static Pressure (ESP)
SWx-3 SWx-2 SWx-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
060-14
Clg Default: OFF OFF OFF 1060 1070 1080 1080 1075 1065 1050 1035 1025 1010
CF Default: OFF OFF OFF 545 530 520 525 510 Seenote4
Cooling (SW2)
Cont Fan
(SW3)
OFF OFF ON 545 530 520 525 510 Seenote4
OFF ON OFF 710 710 710 695 690 Seenote4
OFF ON ON 875 880 890 895 895 890 885 880 870 855
ON OFF OFF 1060 1070 1080 1080 1075 1065 1050 1035 1025 1010
ON OFF ON 1235 1240 1250 1255 1255 1250 1230 1190 1155 1115
ON ON OFF 1235 1240 1250 1255 1255 1250 1230 1190 1155 1115
ON ON ON 1235 1240 1250 1255 1255 1250 1230 1190 1155 1115
Clg SW2: Maximum Clg Airflow
2
1425 1425 1405 1370 1335 1300 1260 1225 1190 1155
Heating
(SW1)
High Heat Airflow
3
1075 1085 1095 1095 1090 1080 1065 1050 1035 1020
Low Heat Airflow
3
855 855 860 870 870 865 860 855 845 785
Unit Size Clg/CF Switch Settings External Static Pressure (ESP)
SWx-3 SWx-2 SWx-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
080-14
Clg Default: OFF OFF OFF 1055 1065 1080 1075 1065 1050 1045 1035 1025 1005
CF Default: OFF OFF OFF 520 505 505 495 490 Seenote4
Cooling (SW2)
Cont Fan
(SW3)
OFF OFF ON 520 505 505 495 490 Seenote4
OFF ON OFF 665 685 680 660 665 Seenote4
OFF ON ON 885 895 905 900 900 895 885 875 860 845
ON OFF OFF 1055 1065 1080 1075 1065 1050 1045 1035 1025 1005
ON OFF ON 1245 1245 1255 1255 1260 1255 1250 1235 1220 1185
ON ON OFF 1245 1245 1255 1255 1260 1255 1250 1235 1220 1185
ON ON ON 1245 1245 1255 1255 1260 1255 1250 1235 1220 1185
Clg SW2: Maximum Clg Airflow
2
1520 1485 1450 1415 1375 1335 1300 1265 1225 1190
Heating
(SW1)
High Heat Airflow
3
1520 1485 1450 1415 1375 1335 1300 1265 1225 1190
Low Heat Airflow
3
1055 1065 1080 1075 1065 1050 1045 1035 1025 1005
Unit Size Clg/CF Switch Settings External Static Pressure (ESP)
SWx-3 SWx-2 SWx-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
080-20
Clg Default: OFF OFF OFF 1745 1755 1755 1760 1755 1750 1745 1725 1705 1685
CF Default: OFF OFF OFF 700 710 750 725 750 Seenote4
Cooling (SW2)
Cont Fan
(SW3)
OFF OFF ON 700 710 750 725 750 Seenote4
OFF ON OFF 830 860 870 890 960 Seenote4
OFF ON ON 1045 1045 1060 1070 1070 1070 1095 1090 1080 1070
ON OFF OFF 1215 1220 1245 1240 1235 1235 1225 1220 1235 1235
ON OFF ON 1370 1370 1390 1390 1400 1395 1400 1390 1390 1385
ON ON OFF 1745 1755 1755 1760 1755 1750 1745 1725 1705 1685
ON ON ON 1745 1755 1755 1760 1755 1750 1745 1725 1705 1685
Clg SW2: Maximum Clg Airflow
2
1920 1920 1945 1945 1945 1960 1950 1940 1915 1900
Heating
(SW1)
High Heat Airflow
3
1340 1355 1370 1385 1380 1385 1400 1400 1385 1380
Low Heat Airflow
3
1080 1115 1115 1120 1125 1135 1125 1120 1125 1110
See notes at end of table.
59TN6A
