Carrier Infinity 96 - Typical Installations - Basement & Closet; Basement Upflow Application; Closet Downflow Application

19
Typical installations
Basement — Upflow Application A02307
Closet — Downflow Application A02308
COMBUSTION
AIR PIPE
A/C COIL
OUTDOOR UNIT
VENT PIPE
HUMIDIFIER
GAS-FIRED
WATER HEATER
ELECTRONIC
AIR CLEANER
AIRFLOW
ELECTRONIC
AIR CLEANER
HUMIDIFIER
A/C COIL
VENT
COMBUSTION
AIR
OUTDOOR
UNIT
AIRFLOW
FRONT OF
FURNACE
