54
FURNACE
PIPE DIAMETER
TRANSITION IN
VERTICAL SECTION
NOT IN
HORIZONTAL
SECTION
A93034
Fig. 42 -- Combustion Air and Vent Pipe Diameter Transition Location and Elbow Configuration
L14F028
Fig. 43 -- Inside Corner Termination
59SC2C
