CARSON Reflex Wheel Ultimate Touch 500500516
External View of Transm itter
Stylus for
touchscreen
Trim switch TR1
Trim switch TR4
Interchangeable
grip S/L
Micro USB port
Throttle trigger
Trim switch TR5
Switch SW1
Battery compartment
LCD colour touch
display
Control steering
wheel
Trim switch TR2
Switch SW3
Switch SW2
Status LED
2,4 GHz Aerial
Power switch
On/Off
Trim switch TR3
Slots
1. Steering servo (CH.1)
2. Throttle servo/ESC (CH.2)
3. Terminal for Channel 3 (CH.3)
4. Terminal for Channel 4 (CH.4)
B/VCC: - Power supply
- Binding connector terminal
IN: Telemetry sensors terminal
OUT: No function
Receiver Reflex Wheel Ultimate Touch:
