CARSON Reflex Wheel Ultimate Touch 500500516
Equipm ent fo r Com bustion Engine
RX aerial
Receiver batteries and two servos are not included in the kit.
Advice
To obtain a better range, the RX aerial must be
installed perpendicularly, away from metallic
components.
Receiver
Regard the
form of the
connector!
Receiver switch
Antenna cable
Receiver
To receiver battery
Throttle servo Channel 2
(not included)
Steering servo Channel 1
(not included)
Servo Channel 3
(not included)
Servo Channel 3
(not included)
ATTENTION
When connecting the servo to the receiver
always regard the form of the connector! The
black wire is facing outward!
