Carter CT06 - Page 6

Overall dimensions
Unit: mm
A Wheel track
875
B Overall length of track
1150
C Ground clearance of platform
325
D Distance from the center of rotation to the rear end
758
E Chassis width
730
F Crawler width
150
H Crawler height
285
I Transportation length
2325
J Overall height （ Driving shed top ）
1280
Work range
Unit: mm
A Max. digging radius on ground
2900
B Max. digging depth
1000
C Max. digging height
2512
D Max. unloading height
1613
E Maximum excavation distance at ground level
2860
F Min. swing radius
1483
G Max. lifting height of dozer blade
130
H Max. digging depth of dozer blade
116
Performance parameters
Weight of complete machine kg
700
Standard bucket capacity m³
0.016
Rated power kw
7.0
