Carver 4350 - Section Two; Installation; Manual Pellet Press Description; Setting up

SECTION TWO INSTALLATION
2.1 MANUAL PELLET PRESS DESCRIPTION
CATALOG # 4350
CLAMP FORCE US
TONS
Kn
12
106.8
PLATEN DIA. IN.
MM.
4
101.6
RAM STROKE IN.
MM.
5.125
130
DAYLIGHT
OPENING
IN.
MM.
0-5.5
0- 139.7
FOOTPRINT
W x D
IN.
MM
10.5 x14.125
267 x 359
HEIGHT IN.
MM.
27.875
581
WEIGHT
lbs
Kg
120
54.5
NOISE LEVEL
<70db(A)
MAX. SYSTEM
PRESSURE -
PSI
bar
7295
503
2.2 INSTALLATION
To assist in the installation and operation of this press, an assembly drawing (including part numbers) is included in the
appendix of this manual.
2.3 SETTING UP
Through the opening in the rear of the press enclosure remove the solid plug from the oil fill hole in the jack,
using a 7/16) socket, replace this plug with the provided sintered breather.
IMPORTANT: DO NOT
operate the hydraulic unit with the solid shipping plug in the oil fill hole or damage to the
hydraulic unit may occur.
The CARVER Manual Pellet Press was carefully designed with a low center of gravity and an extended base to remain
stable under normal operating conditions.
2.4 RAM FORCE CALCULATION
2-1
