emptying the waste tank and/oR gRay wateR tank:




Waste Plate Location 
 







1 1/2” Odor Safe Hose (Typical)
70 Gallon Waste Tank, 270 L
VIP Stateroom Head/Toilet
Master Stateroom Head/Toilet
OVERBOARD DISCHARGE SYSTEM
(ApplicAble ONlY if iNstAlled)
1/2” Discharge Vented Loop
1 1/2” Odor Safe Hose (Typical)
Overboard Discharge Seacock
12V Overboard Discharge Pump
waste system oVeRall layout
masteR head
to waste deCk
fitting
engine Room
Se c t i o n 4Se c t i o n 4
74 3957 • C7 08/2013
