Frequency Response: Mic or Line Inputs: 20Hz-20KHz ±2dB
Total Harmonic Distortion: Less than .025%
Equivalent Input Noise: 150 ohm source: -120dBV
Output Noise: -80dBu non-powered mixers
(All Levels Minimum) -60dBu powered mixers
Output Power: CX1252: 250Watts RMS/side @ 4Ω
(Power Mixers Only) CX842: 200Watts RMS/side @ 4Ω
Maximum Gain: Mic in two-track main out: 70dB
Crosstalk: Adjacent ch’s: -60db at 1KHz
Common Mode Rejection: -60db at 1KHz
Phantom Power: All channels
Channel EQ.: 3 band active, LOW: 100Hz ±12dB
MID: 1.5KHz ±12dB
HI: 10KHz ±12dB
Graphic EQ.: 9 Band Oct. Intervals ±12dB
Mic Input: Balanced XLR input: -60 dBu
Line Input: Unbalanced 1/4” Phone Jack -10dBV
Power Consumption: CX1252: 620VA, CX842: 540VA
Size: Box Model: (25lbs) 11”H x 19.5”W x9”D
Rack Model: 8.75”H x 19”W x 7.75”D
CX MIXER SPECIFICATIONS
Fuse Selector Chart for 120 VAC Models
Model Fuse Value Carvin # Size
CX1252 6A, 250V, Slow Blow 70-22060 3AG, 1/4 x 1 1/2” (6.35 x 32mm)
CX1252R 0.25A, 250V, Slow Blow 70-21002 3AG, 1/4 x 1 1/2” (6.35 x 32mm)
CX842 6A, 250V, Slow Blow 70-22060 3AG, 1/4 x 1 1/2” (6.35 x 32mm)
FUSE SELECTION
Fuse Selector Chart for 240 VAC EXPORT Models
Model Fuse Value Carvin # Size
CX1252 3A, 250V, Slow Blow 70-22030 3AG, 1/4 x 1 1/2” (6.35 x 32mm)
CX1252R 0.125A, 250V, Slow Blow 70-21001 3AG, 1/4 x 1 1/2” (6.35 x 32mm)
CX842 3A, 250V, Slow Blow 70-22030 3AG, 1/4 x 1 1/2” (6.35 x 32mm)
There are two versions of the CX842 and the CX1252. A 120 Volt AC version using
the North American three prong plug and a 240 Volt AC version using the European
CEE-7 plug. The following chart shows what fuse values to use for each model.
i
INSPECT YOUR CX MIXER FOR ANY DAMAGE which may have occurred
during shipping. If any damage is found, notify the shipping company and call
CARVIN immediately.
SAVE THE CARTON & ALL PACKING MATERIALS. If you have to reship
your mixer, always use the original carton and packing material. This will provide
the best possible protection for the mixer during shipment. CARVIN and the
shipping company are not liable for any damage caused by improper packing.
SAVE YOUR INVOICE. It will be required for warranty servicing of your unit.
Always check the invoice against the items you have received.
SHIPMENT SHORTAGE. If you find some items missing, it may be that they
were shipped separately. Please allow several days for the rest of your order to
arrive before inquiring. If you determine (after allowing an appropriate amount of
time) you have not received all the items you ordered, please call CARVIN.
Congratulations on your selection of CARVlN products: “The Professional’s
Choice.” Your new CX series mixer demonstrates CARVIN’s commitment to
producing the highest quality and most sophisticated engineering in the audio
industry today. Its wide acceptance and use by industry professionals illustrates
the basis for CARVIN’s recognition as “The Professional’s Choice.”
The CX series mixers were designed to be a professional quality mixer in a com-
packed package. The desire was to pack as many professional features into the
smallest package we could, without sacrificing the quality of any one of the fea-
tures or the mixer. The CX1252 includes a full function 12 channel stereo mixer,
two nine band graphic equalizers, a 128 preset digital signal effects processor,
and a 500 Watt stereo power amplifier capable of 250 Watts a side into 4 ohms.
The CX842 is an 8 channel stereo mixer with a 400 Watt power amplifier. The
CX842 has all the features of the CX1252 including the two nine band graphic
equalizers and the effects processor. Each CX series mixer is the size of a 5
space rackmount unit surrounded by a 3/4” poplar plywood cabinet covered with
Duratuff carpeting making the CX mixer road worthy and ready for a show any-
where.
If you would like to comment on any features or the performance of your new
mixer, please feel free to contact us. Comments from our customers have
helped us to improve and further develop our products and our business.
May you enjoy many years of success and fun with your new CARVIN mixer!
Carvin’s toll free number: 800-854-2235
RECEIVING INSPECTION
FOR THE NEW OWNER
