CARVIN ENGINEERING DATACARVIN ENGINEERING DATA
SET UPSET UP
IN EAR MONITOR SYSTEMIN EAR MONITOR SYSTEM
PG. 7
LEVEL MAX TIME
>115dB SPL NONE
115dB SPL 28 seconds
112dB SPL 56 seconds
109dB SPL 1 minute 52 seconds
106dB SPL 3 minutes 45 seconds
103dB SPL 7 minutes 30 seconds
100dB SPL 15 minutes
97dB SPL 30 minutes
94dB SPL 1 hour
91dB SPL 2 hours
88dB SPL 4 hours
85dB SPL 8 hours
82dB SPL 16 hours
80dB SPL 24 hours (continuous)
Part# Description
EM900ANT
Replacement antenna for
EM900
EM901BATT
Replacement battery
compartment
EMBATCLIP-4
Set of 4 battery
compartment retention clips
EM901CLIP EM901 body pack clip
OSHA Recommended Maximum Exposure
Time To Avoid Hearing Loss
ADVANCED SETUPS:
» A. MULTIPLE SYSTEMS: Up to 16 separate EM900
transmitters can be used at one time, with
unlimited EM901 receivers.
» B. MULTIPLE RECEIVERS: To use multiple
receivers to monitor the same mix, simply set
the receivers to the same frequency as the
transmitter. Additional EM901 receivers
are available from Carvin Audio.
» C. MULTIPLE TRANSMITTERS WITH SAME MIX:
To connect multiple transmitters
to the same source, connect 1/4” cables
from the LOOP OUT connector of the first unit
into the INPUTS of the second unit. This can be
useful in areas with very
unpredictable RF conditions to provide better
coverage and for redundant backups.
SPARE PARTS
EM900 Audio Out
