Function setting
Uses dipswitches to assign a unit’s function: DMX/slave, or sound active, or AUTO
mode.For the unit is DMX mode, set the DMX address. Each dipswitch represents a
binary value. See the “Function chart”.
Rear Panel Figure
1. Power Jack 2. Cooling Fan
Dipswitch #10 is use to set master or slave mode. Master modes have sound active and
3. Audio Sensitivity Knob 4. DMX Signal Indicator: Green
AUTO mode.Slave modes have DMX and Slave mode. The units automatically identify
5. Dipswitches: Function Setting 6. DMX or Linking Jack
DMX or SLAVE mode by data receives. Dipswitch #9 use to is set sound active or AUTO
7. ON/OFF 8. Sound Active Microphone/ Power Indicator mode in master mode.
DMX address calculation
Operation
For DMX mode, DMX512 address from #1 to 9# dipswitches must be set, the
address is set from 1 to 511. Each dipswitch represents a binary value.
Master-Slave Operation
Dipswitch Value Dipswitch Value
＃1
1
＃6
32
This mode will allow you to link up to 32 units together without controller.
＃2
2
＃7
64
＃3
4
＃8
128
Install the units in a suitable position (laying or appending).
＃4
8
＃9
256
Turn on the all units' power, the units begins reset, then the unit begins working. The slave
＃5
16
＃10
Set to "0"
units will react the same as the master unit.
One unit has 7 channels, so each unit must be assigns 7 channels at least. We may
Choose a unit to function as Master mode, set dipswitch to select Sound Active or AUTO
assign 8 channels for one unit, then DMX address = 8*N + 1, N=0, 1, 2, 3 ……
mode. The others must be set to Slave mode, set dipswitch to select Slave mode.
Example
Use standard XLR microphone cable chain your units together via the XLR connector on One loop address=1, two loop address=9, three loop address=17, four loop address=25
the rear of the units. For longer cable runs we suggest a terminator at the last fixture.
Loop Address Binary Dipswitches
The units will react to the low frequencies of music via the internal microphone. Adjust the
1 1 100000000 ＃1
audio sensitivity knob on the back of the master unit to make the unit more or less sensi-
2 9 100100000 ＃1+#4
tive in sound active.The panel has LED indicating for sound active.
3 17 100010000 ＃1+#5
4 25 100110000 ＃1+#4+#5
6 3
Function Chart
1
5
6
2
3
4
2
7 8
