INSTALLATION
Installation
INSTALLATION
Installation
4 – STOP MASSAGE / MEMORY FUNCTION
1. Press the Power button on the Remote Control at any time during the massage to stop all massage
functions. The back rest and footrest reset to their starting positions.
2. Within this time you can set the memory function. Note that while the memory function can be set,
during memory setting the back and foot rest will not go back to their starting positions.
3. To set Memory, press M1 or M2 within 10 seconds of massage cycle completion to save the adjust-
ments of the last massage.
Diagram of the switch position of power supply
Power switch method map
WARNING
Thanks to the safety switch in the power supply
vox, the chair automatically stops all functions,
when there is too much pressure on that part of
the chair. this way, it prevents people from getting
injured.
5 – CALF INSTALLATION
a) Install the rotating shaft into the fixed axle. Please pay attention to the correct alignment of the
R-pin. (Chart 1)
b) After the fixed axle is aligned and connected correctly, put everything together as shown in the
second picture. (Chart 2)
Chart 1
Chart 2
c) As shown in Chart 3, please close the R-pin on the other side of the foot rest.
d) Finished Installation. (Chart 4)
Chart 3
Chart 4
NOTE
• To avoid injuries and damaging the product, the foot rest should not be pressed down or lifted up by
hand during the massage.
• To avoid an uncomfortable sitting position, ensure that the massage mechanism does not stop while
in the area of the still in the seat cushion. (Chart 2)
Chart 1
Chart 2
