Case IH 3230 - Optional Wheel Kit - 120 Booms

CHAPTER 2
14 Case IH 3230/3240/3320/3330/3340 & 4420/4430/4440, Model Year 2010 & Newer ISO AutoBoom® Installation Manual
OPTIONAL WHEEL KIT - 120’ BOOMS
Bolt - 1/2”-13 x 1-1/2” SS Hex 311-0058-186 4
Nut - 1/2”-13 Zinc Plated Hex 312-1001-043 4
Nut - 3/8”-16 Zinc Flanged Lock 312-1001-164 16
TABLE 6. Optional Wheel Kit (P/N 117-0133-075)
Picture Item Description Part Number Qty.
Axle Assembly - Straight AutoBoom 063-0131-567 2
Bracket - CaseIH 120’ Boom Weldment 116-0159-680 2
Wheel 322-0131-008 2
U-Bolt - 2-1/16” W x 3” L x 3/8” Thread 107-0171-609 8
Bolt - 1/2”-13 x 1-1/2” Stainless Steel Hex 311-0058-186 4
TABLE 5. Optional Wheel Kit (P/N 117-0134-006)
Picture Item Description Part Number Qty.
