Engine-Engineandcrankcase
Engine-Remove
Prioroperation:
Separatethefrontaxleandfrontframefromtheengine,seeFrontframe-Remove(39.100).
Prioroperation:
Removetheleft-handfueltank,seeFueltank-Remove(10.216).
Prioroperation:
Removetheselectivecatalyticreduction(SRC)mufer,seeSelectiveCatalyticReduction(SCR)muferandcat-
alyst-Remove(10.500).
Prioroperation:
Removetheenginehood,seeHood-Remove(90.100).
WARNING
Heavyobjects!
Liftandhandleallheavycomponentsusinglift-
ingequipmentwithadequatecapacity.Always
supportunitsorpartswithsuitableslingsor
hooks.Makesuretheworkareaisclearofall
bystanders.
Failuretocomplycouldresultindeathorseri-
ousinjury.
W0398A
WARNING
Avoidinjury!
Handleallpartscarefully.Donotplaceyour
handsorngersbetweenparts.UsePersonal
ProtectiveEquipment(PPE)asindicatedinthis
manual,includingprotectivegoggles,gloves,
andsafetyfootwear.
Failuretocomplycouldresultindeathorseri-
ousinjury.
W0208A
1.Removethestartermotorshield.
