Engine-Engineandcrankcase
6.Removetheright-handfueltanksupportbracketrear
retainingbolts.
BAIL15TR00809AA6
7.Removetheright-handfueltanksupportbracket:
A.Usingsuitableliftingequipment,supportthe
bracket(1).
B.Removetheretainingbolt(2).
BAIL15TR00811AA7
8.Removetheleft-handfueltanksupportbracketrear
retainingbolts.
BAIL15TR00813AA8
9.Removetheleft-handfueltanksupportbracket:
A.Usingsuitableliftingequipment,supportthe
bracket(1).
B.Removetheretainingbolt(2).
BAIL15TR00814AA9
4819316130/11/2017
