Case IH PUMA 130 - Technical Data and Maintenance Guidance; Torque Specifications

INTRODUCTION
Torque
Minimumhardwaretighteningtorques(inNmorlbin/lbft)fornormalassemblyapplica-
tionsunlessotherwisestated
NOTICE:Shownbelowisthesuggestedinitialtorquetighteningsequencesforgeneralapplications,tighteninse-
quencefromitem1throughtothelastitemofthehardware.
Theminimumhardwaretighteningtorqueondrawings,inspecicationsetc.havepriority.
TheapplicableCNHStandardisENS7001.
df5019-11
Metrichardware
Class8.8inNm(lbinorlbft)Class10.9inNm(lbinorlbft)
Nominal
Size
PlatednutLocknutHardenednutPlatednutLocknutHardenednut
M31.3N·m
(11.5lbin)
0.7N·m
(6.2lbin)
1.2N·m
(10.6lbin)
1.8N·m
(15.9lbin)
0.9N·m
(8.0lbin)
1.6N·m
(14.2lbin)
M42.9N·m
(25.7lbin)
1.6N·m
(14.2lbin)
2.6N·m
(23.0lbin)
4.2N·m
(37.2lbin)
2.3N·m
(20.4lbin)
3.7N·m
(32.7lbin)
M55.9N·m
(52.2lbin)
3.2N·m
(28.3lbin)
5.3N·m
(46.9lbin)
8.5N·m
(75.2lbin)
4.6N·m
(40.7lbin)
7.6N·m
(67.3lbin)
M610.1N·m
(89.4lbin)
5.5N·m
(48.7lbin)
9.1N·m
(80.5lbin)
14.5N·m
(10.7lbft)
7.9N·m
(69.9lbin)
13N·m
(9.6lbft)
M824.5N·m
(18.1lbft)
13.5N·m
(10.0lbft)
22N·m
(16.2lbft)
35.1N·m
(25.9lbft)
19.3N·m
(14.2lbft)
31.5N·m
(23.2lbft)
M1048.7N·m
(35.9lbft)
26.8N·m
(19.8lbft)
43.8N·m
(32.3lbft)
69.5N·m
(51.3lbft)
38.2N·m
(28.2lbft)
62.5N·m
(46.1lbft)
M1285N·m
(62.7lbft)
46.7N·m
(34.4lbft)
76.5N·m
(56.4lbft)
121N·m
(89.2lbft)
66.5N·m
(49.0lbft)
108.9N·m
(80.3lbft)
M14135N·m
(99.6lbft)
74.2N·m
(54.7lbft)
121.5N·m
(89.6lbft)
193N·m
(142.3lbft)
106.1N·m
(78.3lbft)
173.7N·m
(128.1lbft)
M16210N·m
(154.9lbft)
115.5N·m
(85.2lbft)
189N·m
(139.4lbft)
301N·m
(222lbft)
165.5N·m
(122.1lbft)
270.9N·m
(199.8lbft)
M18299N·m
(220.5lbft)
164.4N·m
(121.3lbft)
269.1N·m
(198.5lbft)
414N·m
(305.4lbft)
227.7N·m
(167.9lbft)
372.6N·m
(274.8lbft)
M20425N·m
(313.5lbft)
233.72N·m
(172.4lbft)
382.5N·m
(282.1lbft)
587N·m
(432.9lbft)
322.8N·m
(238.1lbft)
528.3N·m
(389.7lbft)
M22579N·m
(427lbft)
318.4N·m
(234.8lbft)
521.1N·m
(384.3lbft)
801N·m
(590.8lbft)
440.5N·m
(324.9lbft)
720.9N·m
(531.7lbft)
M24735N·m
(542.1lbft)
404.2N·m
(298.1lbft)
661.5N·m
(487.9lbft)
1016N·m
(749.4lbft)
558.8N·m
(412.1lbft)
914.4N·m
(674.4lbft)
M271073N·m
(791.4lbft)
590.1N·m
(435.2lbft)
967.5N·m
(713.6lbft)
1486N·m
(1096lbft)
817.3N·m
(602.8lbft)
1337N·m
(986.1lbft)
M301461N·m
(1077.6lbft)
803.5N·m
(592.6lbft)
1315N·m
(969.9lbft)
2020N·m
(1489.9lbft)
1111N·m
(819.4lbft)
1818N·m
(1340.9lbft)
84479138A06/06/2011
14
