INTRODUCTION
Torque
Minimumhardwaretighteningtorques(inNmorlbin/lbft)fornormalassemblyapplica-
tionsunlessotherwisestated
NOTICE:Shownbelowisthesuggestedinitialtorquetighteningsequencesforgeneralapplications,tighteninse-
quencefromitem1throughtothelastitemofthehardware.
Theminimumhardwaretighteningtorqueondrawings,inspecicationsetc.havepriority.
TheapplicableCNHStandardisENS7001.
df5019-11
Metrichardware
Class8.8inNm(lbinorlbft)Class10.9inNm(lbinorlbft)
Nominal
Size
PlatednutLocknutHardenednutPlatednutLocknutHardenednut
M31.3N·m
(11.5lbin)
0.7N·m
(6.2lbin)
1.2N·m
(10.6lbin)
1.8N·m
(15.9lbin)
0.9N·m
(8.0lbin)
1.6N·m
(14.2lbin)
M42.9N·m
(25.7lbin)
1.6N·m
(14.2lbin)
2.6N·m
(23.0lbin)
4.2N·m
(37.2lbin)
2.3N·m
(20.4lbin)
3.7N·m
(32.7lbin)
M55.9N·m
(52.2lbin)
3.2N·m
(28.3lbin)
5.3N·m
(46.9lbin)
8.5N·m
(75.2lbin)
4.6N·m
(40.7lbin)
7.6N·m
(67.3lbin)
M610.1N·m
(89.4lbin)
5.5N·m
(48.7lbin)
9.1N·m
(80.5lbin)
14.5N·m
(10.7lbft)
7.9N·m
(69.9lbin)
13N·m
(9.6lbft)
M824.5N·m
(18.1lbft)
13.5N·m
(10.0lbft)
22N·m
(16.2lbft)
35.1N·m
(25.9lbft)
19.3N·m
(14.2lbft)
31.5N·m
(23.2lbft)
M1048.7N·m
(35.9lbft)
26.8N·m
(19.8lbft)
43.8N·m
(32.3lbft)
69.5N·m
(51.3lbft)
38.2N·m
(28.2lbft)
62.5N·m
(46.1lbft)
M1285N·m
(62.7lbft)
46.7N·m
(34.4lbft)
76.5N·m
(56.4lbft)
121N·m
(89.2lbft)
66.5N·m
(49.0lbft)
108.9N·m
(80.3lbft)
M14135N·m
(99.6lbft)
74.2N·m
(54.7lbft)
121.5N·m
(89.6lbft)
193N·m
(142.3lbft)
106.1N·m
(78.3lbft)
173.7N·m
(128.1lbft)
M16210N·m
(154.9lbft)
115.5N·m
(85.2lbft)
189N·m
(139.4lbft)
301N·m
(222lbft)
165.5N·m
(122.1lbft)
270.9N·m
(199.8lbft)
M18299N·m
(220.5lbft)
164.4N·m
(121.3lbft)
269.1N·m
(198.5lbft)
414N·m
(305.4lbft)
227.7N·m
(167.9lbft)
372.6N·m
(274.8lbft)
M20425N·m
(313.5lbft)
233.72N·m
(172.4lbft)
382.5N·m
(282.1lbft)
587N·m
(432.9lbft)
322.8N·m
(238.1lbft)
528.3N·m
(389.7lbft)
M22579N·m
(427lbft)
318.4N·m
(234.8lbft)
521.1N·m
(384.3lbft)
801N·m
(590.8lbft)
440.5N·m
(324.9lbft)
720.9N·m
(531.7lbft)
M24735N·m
(542.1lbft)
404.2N·m
(298.1lbft)
661.5N·m
(487.9lbft)
1016N·m
(749.4lbft)
558.8N·m
(412.1lbft)
914.4N·m
(674.4lbft)
M271073N·m
(791.4lbft)
590.1N·m
(435.2lbft)
967.5N·m
(713.6lbft)
1486N·m
(1096lbft)
817.3N·m
(602.8lbft)
1337N·m
(986.1lbft)
M301461N·m
(1077.6lbft)
803.5N·m
(592.6lbft)
1315N·m
(969.9lbft)
2020N·m
(1489.9lbft)
1111N·m
(819.4lbft)
1818N·m
(1340.9lbft)
84479138A06/06/2011
14
