HYDRAULIC,PNEUMATIC,ELECTRICAL,ELECTRONICSYSTEMS-PRIMARYHYDRAULICPOWERSYSTEM
PRIMARYHYDRAULICPOWERSYSTEM-Staticdescription
PUMA130CVT ,PUMA145CVT ,PUMA160CVT
Thehydraulicsystemscanbeseparatedintothefollowingcircuits:-
HighPressureCircuit
HydraulicLiftAssembly.
RemoteControlValves.
TrailerBrake(WhereFitted)
SuspendedFrontAxle.
FrontLift(Wheretted).
SteeringCircuit
SteeringMotorandCylinders
LowPressureCircuit
IndependentPowerT akeOff(PTO).
DifferentialLock
FrontWheelDriveengagement
Transmissionclutchandsynchroniserengagement
Creeperengagement(Wheretted)
FrontPTO(Wheretted)
50kphengagement(Wheretted)
HydrostaticUnit
LubricationCircuit
PTOClutchPlates
TransmissionClutchPlates.
TransmissionShaftPressureLube
PumpDriveGearBearing.
HydraulicLiftCrossShaft
Options/Congurations
HydraulicPump/HPL/RemoteValveOptions
LessHydraulicTrailerBrakesWithHydraulicTrailerBrakesHydraulicTrailerBrakeItaly
VariableDisplacementPump.
ElectronicDraftControlvalve(EDCvalve)
MechanicalRemote
Valves
1NonCongurable+2Congurable
2NonCongurable+2Congurable
Electro-Hydraulic
RemoteValves
3,4or5Electrohydraulicallyoperatedvalves
84479138A06/06/2011
A.10.A/17
